Kinetix 5700 Servo Drives
Kinetix 5700 Drive Module Selection
For Kinetix 5700 drive module specifications not included in this publication, refer to the Kinetix Servo Drives Technical Data, publication
KNX-TD003
.
Kinetix 5700 Drive Modules
Module Cat. No.
(1)
(1) Throughout this publication, when the Kinetix 5700 inverter catalog number ends in -ERSx, for example 2198-D057-ERSx, the variable (x) indicates that the inverter catalog number can be
-ERS3 or -ERS4.
Module Width
mm
Continuous Output
Power
kW
Continuous Output
Current to Bus
A
DC
rms
Continuous Output
Current
A 0-pk
DC-bus Power Supply
(195…528V AC rms,
three-phase input power)
2198-P031
2198-P070
55
7
17
10.5
25.5
–
2198-P141
2198-P208
85
31
46
46.9
69.2
Regenerative Power Supply
(324…506V AC rms,
three-phase input power)
(2)
(2) Applies when DC-bus voltage regulation is enabled. If DC-bus voltage regulation is not enabled, the input voltage range is 324….528V AC. For more information on these two modes of
operation, see the Kinetix 5700 Servo Drives User Manual, publication 2198-UM002.
2198-RP088 165 24 35.3
–
2198-RP200 275 67 100.0
2198-RP263
440
119 176.4
2198-RP312 140 207.0
Dual-axis Inverters
2198-D006-ERS3
2198-D012-ERS3
2198-D020-ERS3
2198-D032-ERS3
2198-D006-ERS4
2198-D012-ERS4
2198-D020-ERS4
2198-D032-ERS4
55
1.7
3.4
5.5
8.9
–
3.5
7.0
11.3
18.3
2198-D057-ERS3 2198-D057-ERS4 85 15.9 32.5
Single-axis Inverters
2198-S086-ERS3
2198-S130-ERS3
2198-S086-ERS4
2198-S130-ERS4
85
29.7
44.9
–
60.8
91.9
2198-S160-ERS3 2198-S160-ERS4 100 60.1 120.2
2198-S263-ERS3 2198-
S312-ERS3
2198-S263-ERS4
2198-S312-ERS4
220
90
112
212.1
271.5
To Next Page
