Kinetix 5700 Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix HPK Motor Performance Specifications with Kinetix 5700 Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPS Motor Performance Specifications with Kinetix 5700 (400V operation) Drives
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
MPS-B330P 5000 5000 4.9 3.60 (32)
17.6 10.5 (92.9)
1.3
2198-D012-ERSx
19.0 11.0 (97.2) 2198-D020-ERSx
MPS-B4540F 3000 3000 7.1 8.1 (72)
17.6 19.2 (170)
1.4
2198-D012-ERSx
26.0 27.1 (240) 2198-D020-ERSx
MPS-B560F 3000 3000 17.0 21.5 (190)
45.9 49.7 (440)
3.5
2198-D032-ERSx
68.0 67.8 (600) 2198-D057-ERSx
Kinetix HPK (460V) Motor Performance Specifications with Kinetix 5700 Drives
Motor Cat. No.
Base Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak Stall
Current
A 0-pk
System Peak Stall
Torque
N•m (lb•in)
Motor Rated Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
HPK-B1307C
1500 3000
48.2 112 (991) 113.0 260 (2301) 17.1 (22.9) 2198-S086-ERSx
HPK-B1308C 59.6 141 (1248) 119.3 262 (2319) 21.6 (28.9) 2198-S086-ERSx
HPK-B1310C 64.9 155 (1372) 144.0 325 (2876) 23.8 (31.9) 2198-S130-ERSx
HPK-B1613C 109.8 271 (2398) 217.0 542 (4797) 41.7 (55.9) 2198-S160-ERSx
HPK-B1307E
3000 5000
81.0 96.0 (849) 146.6 165 (1460) 29.8 (39.9) 2198-S130-ERSx
HPK-B1308E 91.4 115 (1018) 190.3 230 (2036) 35.7 (47.8) 2198-S160-ERSx
HPK-B1609E 120.2 150 (1327) 217.0 270 (2390) 46.5 (62.3) 2198-S160-ERSx
HPK-B1611E 3000 5000 149.0 183 (1619) 338.4 400 (3540) 57.0 (76.4) 2198-S263-ERSx
HPK-B1815C 1500 3000 153.7 360 (3186) 402.0 850 (7523) 55.9 (74.9) 2198-S312-ERSx
HPK-B1613E 3000 5000 191.0 237 (2097) 440.0 520 (4602) 73.7 (98.8) 2198-S312-ERSx
HPK-B2010C 1500 3000 196.4 482 (4266) 440.0 970 (8585) 75.0 (100.5) 2198-S312-ERSx
HPK-B2010E 3000 5000 254.0 295 (2611) 440.0 500 (4425) 92.0 (123.4) 2198-S312-ERSx
HPK-B2212C 1500 3000 254.0 607 (5372) 440.0 1105 (9780) 94.0 (126.1) 2198-S312-ERSx
Kinetix HPK (400V) Motor Performance Specifications with Kinetix 5700 Drives
Motor Cat. No.
Base Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak Stall
Current
A 0-pk
System Peak Stall
Torque
N•m (lb•in)
Motor Rated Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
HPK-E1307C
1500 3000
58.5 112 (991) 146.6 263 (2327) 17.1 (22.9) 2198-S130-ERSx
HPK-E1310C 80.0 155 (1372) 200.0 380 (3363) 23.8 (32.4) 2198-S160-ERSx
HPK-E1307E
3000 5000
102.0 96.0 (849) 217.0 202 (1788) 29.8 (39.9) 2198-S160-ERSx
HPK-E1308E 112.8 107 (947) 217.7 200 (1770) 33.2 (45.0) 2198-S160-ERSx
HPK-E1613C
1500 3000
133.0 271 (2399) 310.0 625 (5532) 41.7 (55.9) 2198-S263-ERSx
HPK-E1815C 187.0 360 (3186) 440.0 840 (7435) 55.9 (75.0) 2198-S312-ERSx
HPK-E2010C 243.0 482 (4266) 440.0 870 (7700) 75.0 (100.6) 2198-S312-ERSx
HPK-E1609E
3000 5000
153.7 156 (1381) 356.7 359 (3177) 48.4 (64.9) 2198-S263-ERSx
HPK-E1611E 185.0 183 (1620) 440.0 430 (3806) 45.0 (60.3) 2198-S312-ERSx
HPK-E1613E 242.5 237 (2098) 440.0 430 (3806) 73.7 (98.8) 2198-S312-ERSx
