Kinetix 5700 Servo Drives
Kinetix VPH Motor Performance Specifications with Kinetix 5700 Drives
Kinetix VPH (non-brake) Motor Performance Specifications with Kinetix 5700 (200V operation) Drives
Kinetix VPH (brake) Motor Performance Specifications with Kinetix 5700 (200V operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix VPH (non-brake) Motor Performance Specifications with Kinetix 5700 (400V operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(240V AC input)
VPH-A0633F-xxx2 4500 4500 2.91 1.09 (9.7)
8.80 2.86 (25.3)
0.45 (0.61)
2198-D006-ERSx
12.60 4.09 (36.2) 2198-D012-ERSx
VPH-A0753F-xxx2 4600 4600 5.28 1.90 (16.8)
17.70 4.89 (43.3)
0.68 (0.92)
2198-D012-ERSx
25.34 7.00 (62.0) 2198-D020-ERSx
VPH-A1003F-xxx2 5500 5500 11.95 3.41 (30.1)
45.90 10.24 (90.6)
1.32 (1.77)
2198-D032-ERSx
50.00 11.15 (98.7) 2198-D057-ERSx
VPH-A1152E-xxx2 3300 3300 8.01 4.04 (35.8)
28.30 11.57 (102.4)
1.07 (1.43)
2198-D020-ERSx
32.10 13.12 (116.1) 2198-D032-ERSx
VPH-A1153C-xxx2 2300 2300 7.05 5.17 (45.8)
17.70 10.90 (96.5)
1.11 (1.49)
2198-D012-ERSx
33.00 20.33 (179.9) 2198-D032-ERSx
VPH-A1304D-xxx2 3000 3000 14.18 8.44 (74.7)
45.90 21.45 (189.9)
1.79 (2.40)
2198-D032-ERSx
58.00 27.10 (239.9) 2198-D057-ERSx
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(240V AC input)
VPH-A0633F-xxx4 4500 4500 2.91 1.07 (9.5)
8.80 2.86 (25.3)
0.43 (0.57)
2198-D006-ERSx
12.60 4.09 (36.2) 2198-D012-ERSx
VPH-A0753F-xxx4 4600 4600 5.00 1.73 (15.3)
17.70 4.89 (43.3)
0.60 (0.80)
2198-D012-ERSx
25.34 7.00 (62.0) 2198-D020-ERSx
VPH-A1003F-xxx4 5500 5500 11.70 3.18 (28.2)
45.90 10.24 (90.6)
1.06 (1.42)
2198-D032-ERSx
50.00 11.15 (98.7) 2198-D057-ERSx
VPH-A1152E-xxx4 3300 3300 7.83 4.00 (35.4)
28.30 11.57 (102.4)
1.07 (1.43)
2198-D020-ERSx
32.10 13.12 (116.1) 2198-D032-ERSx
VPH-A1153C-xxx4 2300 2300 6.93 5.03 (44.5)
17.70 10.90 (96.5)
1.11 (1.49)
2198-D012-ERSx
33.00 20.33 (179.9) 2198-D032-ERSx
VPH-A1304D-xxx4 3000 3000 13.72 8.27 (73.2)
45.90 21.45 (189.9)
1.79 (2.40)
2198-D032-ERSx
58.00 27.10 (139.9) 2198-D057-ERSx
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
VPH-B0632T-xxx2 8000 8000 2.44 0.84 (7.5) 8.75 2.69 (24.0) 0.52 (0.69) 2198-D006-ERSx
VPH-B0633M-xxx2 6700 6700 2.05 1.03 (9.2) 8.75 4.09 (36.0) 0.50 (0.67) 2198-D006-ERSx
VPH-B0753F-xxx2 6600 6600 3.68 1.87 (16.6)
17.60 6.54 (58.0)
0.74 (0.99)
2198-D012-ERS
x
18.90 7.02 (62.0) 2198-D020-ERSx
VPH-B1001F-xxx2 5000 5000 2.19 1.44 (12.8) 7.10 3.61 (32.0) 0.70 (0.93) 2198-D006-ERSx
VPH-B1003F-xxx2 4750 4750 4.93 3.43 (30.4)
17.60 9.71 (86.0)
1.36 (1.83)
2198-D012-ERSx
20.20 11.15 (99.0) 2198-D020-ERSx
VPH-B1152F-xxx2 4500 4500 5.15 4.03 (35.7)
17.60 10.89 (96.4)
1.37 (1.84)
2198-D012-ERSx
21.19 13.12 (116) 2198-D020-ERSx
VPH-B1153E-xxx2 3900 5000 7.09 5.13 (45.4)
17.60 10.84 (96.0)
1.27 (1.70)
2198-D012-ERSx
33.00 20.33 (180) 2198-D032-ERSx
VPH-B1304E-xxx2 3500 3500 8.10 8.41 (74.5)
28.20 23.74 (210)
2.15 (2.88)
2198-D020-ERSx
33.76 28.45 (252) 2198-D032-ERSx
VPH-B1653D-xxx2 3000 3000 14.72 18.67 (165)
45.90 45.77 (405)
3.16 (4.23)
2198-D032-ERSx
68.0 67.80 (600) 2198-D057-ERSx
