98 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 5500 Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPF Motor Performance Specifications with Kinetix 5500 Drives
These motors require the 2198-H2DCK feedback converter kit.
Performance Specifications with Kinetix 5500 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
MPM-B1153F 3000 4000 5500 9.20 6.5 (57.5)
28.3 17.9 (158)
1.40
2198-H025-ERSx
32.0 19.8 (175) 2198-H040-ERSx
MPM-B1153T 6000 4000 7000 15.95 6.5 (57.5)
45.9 14.8 (131)
1.45
2198-H040-ERSx
55.5 16.5(146) 2198-H070-ERSx
MPM-B1302F 3000 4000 4500 8.57 6.6 (58.4) 22.1 13.5 (119) 1.65 2198-H025-ERSx
MPM-B1302M 4500 4000 6000 12.57 6.6 (58.4) 32.4 13.5 (119) 1.65 2198-H040-ERSx
MPM-B1302T 6000 4000 7000 16.83 6.7 (59.3) 43.4 13.5 (119) 1.65 2198-H040-ERSx
MPM-B1304C 1500 1870 2750 7.00 10.3 (91.1)
17.7 22.8 (202)
2.00
2198-H015-ERSx
21.5 27.1 (240) 2198-H025-ERSx
MPM-B1304E 2250 3500 4000 10.75 10.2 (90.3)
28.3 23.4 (207)
2.20
2198-H025-ERSx
34.2 27.1 (240) 2198-H040-ERSx
MPM-B1304M 4500 3500 6000 19.02 10.4 (92.0) 60.6 27.1 (240) 2.20 2198-H070-ERSx
MPM-B1651C 1500 3000 3500 10.21 11.4 (101)
28.3 22.7 (201)
2.50
2198-H025-ERSx
29.2 23.2 (205) 2198-H040-ERSx
MPM-B1651F 3000 3000 5000 17.75 11.4 (101)
45.9 21.9 (194)
2.50
2198-H040-ERSx
50.9 23.2 (205) 2198-H070-ERSx
MPM-B1651M 4500 3000 5000 22.46 11.4 (101) 56.8 23.2 (205) 2.50 2198-H070-ERSx
MPM-B1652C 1500 2500 2500 11.51 16.0 (142) 33.6 40.0 (354) 3.80 2198-H040-ERSx
MPM-B1652E 2250 3500 3500 20.94 21.1 (187) 60.5 48.0 (425) 4.30 2198-H070-ERSx
MPM-B1652F 3000 3500 4500 28.74 21.1 (187) 84.1 48.0 (425) 4.30 2198-H070-ERSx
MPM-B1653C 1500 2000 2500 20.05 26.7 (236) 59.2 67.8 (600) 4.60 2198-H070-ERSx
MPM-B1653E 2250 3000 3500 27.00 26.8 (237) 72.9 62.0 (549) 5.10 2198-H070-ERSx
MPM-B2152C 1500 2000 2500 27.40 36.7 (325) 55.4 72.3 (640) 5.60 2198-H070-ERSx
MPM-B2153B 1250 1750 2000 24.06 48.0 (425) 60.0 101.1 (895) 6.80 2198-H070-ERSx
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 5500 Drives
(240V AC input)
MPF-A310P 4750 5000 4.50 1.58 (14.0) 14.0 3.61 (31.9) 0.73 2198-H015-ERSx
MPF-A320H 3350 3500 6.10 3.05 (27.0)
17.7 7.33 (64.9)
1.0
2198-H015-ERSx
19.3 7.91 (70.0) 2198-H025-ERSx
MPF-A320P 4750 5000 9.00 3.05 (27.0)
28.3 7.59 (67.2)
1.3
2198-H025-ERSx
29.5 7.91 (70.0) 2198-H040-ERSx
MPF-A330P 5000 5000 12.0 3.85 (34.0) 38.0 10.32 (91.2) 1.6 2198-H040-ERSx
MPF-A430H 3500 3500 12.2 6.21 (55.0) 45.0 19.82 (175) 1.8 2198-H040-ERSx
MPF-A430P 5000 5000 16.80 5.94 (52.5)
45.9 14.4 (127)
1.9
2198-H040-ERSx
67.0 19.80 (175) 2198-H070-ERSx
MPF-A4530K 4000 4000 19.50 8.08 (71.4) 62.0 20.30 (179) 2.3 2198-H070-ERSx
MPF-A4540F 3000 3000 18.40 10.15 (89.7)
45.9 22.09 (195)
2.5
2198-H040-ERSx
58.0 27.10 (239) 2198-H070-ERSx
Performance Specifications with Kinetix 5500 (400V-class operation) Drives (continued)
Motor Cat. No.
Speed, base
rpm
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5500 Drives
(480V AC input)
