Kinetix 5700 Servo Drives
Kinetix VPL Motor Performance Specifications with Kinetix 5700 (400V operation) Drives
Motor Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A (0-pk)
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
VPL-B0631T 8000 8000 1.20 0.46 (4.0) 4.20 1.33 (12.0) 0.31 (0.42) 2198-D006-ERSx
VPL-B0631U 8000 8000 1.92 0.46 (4.0) 6.48 1.33 (12.0) 0.31 (0.42) 2198-D006-ERSx
VPL-B0632F 4600 4600 1.20 0.93 (8.0) 4.20 2.69 (24.0) 0.37 (0.50) 2198-D006-ERSx
VPL-B0632T 8000 8000 2.55 0.93 (8.0) 8.75 2.69 (24.0) 0.54 (0.72) 2198-D006-ERSx
VPL-B0633M 6500 6700 2.50 1.27 (11.0) 8.75 4.09 (36.0) 0.57 (0.76) 2198-D006-ERSx
VPL-B0633T 6500 8000 3.52 1.27 (11.0)
8.80 2.87 (25.0)
0.57 (0.76)
2198-D006-ERSx
12.60 4.09 (36.0) 2198-D012-ERSx
VPL-B0751M 8000 8000 2.90 1.01 (9.0)
8.80 2.20 (19.0)
0.54 (0.72)
2198-D006-ERSx
9.12 2.27 (20.0) 2198-D012-ERSx
VPL-B0752E 4900 4900 2.70 1.61 (14.0)
8.80 4.10 (36.0)
0.67 (0.90)
2198-D006-ERSx
9.45 4.39 (39.0) 2198-D012-ERSx
VPL-B0752F 7000 7000 3.80 1.61 (14.0) 13.30 4.39 (39.0) 0.80 (1.07) 2198-D012-ERSx
VPL-B0752M 8000 8000 4.90 1.61 (14.0)
17.60 4.10 (36.0)
0.81 (1.09)
2198-D012-ERSx
18.90 4.39 (39.0) 2198-D020-ERSx
VPL-B0753E 4500 4500 3.80 2.28 (20.0) 13.30 7.35 (65.0) 0.81 (1.09) 2198-D012-ERSx
VPL-B0753F 4500 6600 4.09 2.16 (19.0)
17.60 6.55 (58.0)
0.65 (0.87)
2198-D012-ERSx
18.90 7.02 (62.0) 2198-D020-ERSx
VPL-B0753M 6000 8000 6.12 2.28 (20.0)
17.60 5.13 (45.0)
0.82 (1.10)
2198-D012-ERSx
25.34 7.35 (65.0) 2198-D020-ERSx
VPL-B1001M 6000 6000 3.61 1.93 (17.0)
8.80 3.22 (28.0)
1.14 (1.53)
2198-D006-ERSx
10.38 3.78 (33.0) 2198-D012-ERSx
VPL-B1002E 3300 3300 3.44 3.39 (30.0)
8.80 6.47 (57.0)
1.12 (1.50)
2198-D006-ERSx
10.69 7.82 (69.0) 2198-D012-ERSx
VPL-B1002M 6000 6000 6.24 3.39 (30.0)
17.60 6.80 (60.0)
1.86 (2.49)
2198-D012-ERSx
20.33 7.82 (69.0) 2198-D020-ERS
x
VPL-B1003C 2500 2500 3.41 4.18 (37.0)
8.80 9.29 (82.0)
0.96 (1.29)
2198-D006-ERSx
10.61 11.15 (99.0) 2198-D012-ERSx
VPL-B1003F 4750 4750 6.14 4.18 (37.0)
17.60 9.76 (86.0)
1.65 (2.21)
2198-D012-ERSx
20.20 11.15 (99.0) 2198-D020-ERSx
VPL-B1003T 7000 7000 9.58 4.18 (37.0)
28.20 9.76 (86.0)
1.77 (2.37)
2198-D020-ERSx
28.80 11.15 (99.0) 2198-D032-ERSx
VPL-B1152C 2250 2250 3.13 5.10 (45.0)
8.80 10.80 (95.0)
1.06 (1.42)
2198-D006-ERSx
10.74 13.12 (116) 2198-D012-ERSx
VPL-B1152F 4000 4000 6.17 5.10 (45.0)
17.60 10.95 (97.0)
1.40 (1.88)
2198-D012-ERSx
21.19 13.12 (116) 2198-D020-ERSx
VPL-B1152T 6500 6500 10.81 5.08 (45.0)
28.20 12.14 (107)
2.29 (3.07)
2198-D020-ERSx
32.10 13.12 (116) 2198-D032-ERSx
VPL-B1153E 3200 3200 6.13 6.55 (58.0)
17.60 16.85 (149)
1.75 (2.35)
2198-D012-ERSx
21.33 20.33 (180) 2198-D020-ERSx
VPL-B1153F 5000 5000 8.88 6.55 (58.0)
28.20 18.30 (162)
2.30 (3.08)
2198-D020-ERSx
33.0 20.33 (180) 2198-D032-ERSx
VPL-B1303C 2250 2250 6.30 8.80 (78.0)
17.60 19.83 (175)
1.83 (2.45)
2198-D012-ERSx
18.47 20.72 (183) 2198-D020-ERSx
VPL-B1303F 4000 4000 10.10 8.80 (78.0)
28.20 19.85 (175)
2.82 (3.78)
2198-D020-ERSx
31.0 20.72 (183) 2198-D032-ERSx
VPL-B1304C 2150 2150 7.0 10.29 (91.0)
17.60 22.55 (199)
1.75 (2.35)
2198-D012-ERSx
22.3 28.45 (252) 2198-D020-ERSx
VPL-B1304E 3500 3500 9.44 10.29 (91.0)
28.20 25.03 (221)
2.82 (3.78)
2198-D020-ERSx
33.76 28.45 (252) 2198-D032-ERSx
VPL-B1306C 2500 2500 10.80 13.38 (118)
28.20 31.21 (276)
2.46 (3.30)
2198-D020-ERSx
32.94 34.62 (306) 2198-D032-ERSx
VPL-B1306F 4250 4250 14.78 13.38 (118)
45.90 28.50 (252)
2.95 (3.95)
2198-D032-ERSx
55.83 34.62 (306) 2198-D057-ERSx
