Kinetix 300 and Kinetix 350 EtherNet/IP Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance Specifications (frame 70) with Kinetix 300 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance Specifications (frame 50) with Kinetix 300 (200V-class) Drives
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 300 (200V-class) Drives
Single-phase Operation Three-phase Operation
LDAT-S051010-Dxx 2.8
3.1 119 (27) 11.4 363 (82)
0.31
2097-V33PR3
2097-V32PR2
2097-V31PR2
2097-V33PR3
LDAT-S051020-Dxx 3.7 0.38
LDAT-S051030-Dxx 4.1 0.42
LDAT-S051040-Dxx 4.4 0.44
LDAT-S051050-Dxx 4.7 0.46
LDAT-S052010-Dxx 3.7
6.2
251 (56)
22.7
727 (163)
0.79
2097-V33PR5
2097-V32PR4
2097-V33PR5
LDAT-S052020-Dxx 4.8 0.97
LDAT-S052030-Dxx
5.00 1.01LDAT-S052040-Dxx
LDAT-S052050-Dxx
LDAT-S052010-Exx
…
LDAT-S052050-Exx
2.6 3.1 11.4 0.50
2097-V33PR3
2097-V32PR2
2097-V31PR2
2097-V33PR3
LDAT-S053010-Dxx 4.1
9.4
378 (85)
34.2
1093 (246)
1.31
2097-V33PR5
2097-V32PR4
2097-V33PR5
LDAT-S053020-Dxx 5.0 1.53
LDAT-S053030-Dxx
…
LDAT-S053050-Dxx
5.0 1.53
LDAT-S053010-Exx
…
LDAT-S053050-E
xx
1.7 3.1 11.4 0.47 N/A 2097-V33PR3
LDAT-S054010-Dxx 4.4
12.4
509 (114)
45.5
1453 (327)
1.87
2097-V33PR6 2097-V33PR6
LDAT-S054020-Dxx
…
LDAT-S054050-Dxx
5.0 2.05
LDAT-S054010-Exx
…
LDAT-S054050-Exx
2.6 6.2 22.7 1.02
2097-V33PR5
2097-V32PR4
2097-V33PR5
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 300 (200V-class) Drives
Single-phase Operation Three-phase Operation
LDAT-S072010-Dxx
…
LDAT-S072070-Dxx
3.5 6.0
364 (82)
22.0
1055 (237)
1.03
2097-V33PR5
2097-V32PR4
2097-V33PR5
LDAT-S072010-Exx
…
LDAT-S072070-Exx
1.7 3.0 11.0 0.47
2097-V33PR3
2097-V32PR2
2097-V31PR2
2097-V33PR3
LDAT-S073010-Dxx
…
LDAT-S073070-Dxx
3.5 9.0
554 (125)
32.8
1576 (354)
1.57
2097-V33PR5
2097-V32PR4
2097-V33PR5
LDAT-S073010-Exx
…
LDAT-S073070-Exx
1.2 3.0 10.9 0.41 N/A 2097-V33PR3
LDAT-S074010-Dxx
…
LDAT-S074070-Dxx
3.5 11.9
730 (164)
43.5
2088 (469)
2.08 2097-V33PR6 2097-V33PR6
LDAT-S074010-Exx
…
LDAT-S074070-Exx
1.8 6.0 21.7 0.95
2097-V33PR5
2097-V32PR4
2097-V33PR5
LDAT-S076010-Exx
…
LDAT-S076070-Exx
1.8 9.1 1122 (252) 33.2 3189 (717) 1.45
2097-V33PR5
2097-V32PR4
2097-V33PR5
