Rohde & Schwarz RTB2004 - Digitalvoltmeter

Fernsteuerbefehle
R&S
®
RTB2000
373Bedienhandbuch 1333.1611.03 ─ 05
DISPlay:XY:Y2Source <Source>
Defines an optional second source to be displayed in y-direction in an XY-diagram. The
command is only relevant for 4-channel R&S RTB2000 instruments.
Parameter:
<Source> NONE | CH1 | CH2 | CH3 | CH4
*RST: NONE
15.8.5 Digitalvoltmeter
Das DVM-Suffix <m> gibt die Nummer der DVM-Messung an (Messplatz).
DVM<m>:ENABle.......................................................................................................... 373
DVM<m>:SOURce.........................................................................................................373
DVM<m>:TYPE............................................................................................................. 373
DVM<m>:RESult[:ACTual]?............................................................................................ 374
DVM<m>:RESult[:ACTual]:STATus?................................................................................ 374
DVM<m>:ENABle <VoltmeterEnable>
Enables and disables all configured meter measurements.
Suffix:
<m>
.
1..4
The suffix is irrelevant.
Parameter:
<VoltmeterEnable> ON | OFF
*RST: OFF
DVM<m>:SOURce <Source>
Selects an analog channel as the source of the selected meter measurement.
Suffix:
<m>
.
1..4
Sets the number of the meter measurement.
Parameter:
<Source> CH1 | CH2 | CH3 | CH4
CH3 and CH4 are only available with 4-channel instruments.
DVM<m>:TYPE <MeasurementType>
Sets the measurement type for the indicated DVM measurement.
Set OFF to disable the measurement.
