Rohde & Schwarz RTB2004 - Mathematik

Fernsteuerbefehle
R&S
®
RTB2000
303Bedienhandbuch 1333.1611.03 ─ 05
TIMebase:ZOOM:TIME <Time>
Defines the distance of the trigger point to the reference point in the zoom window. The
value determines the position of the zoom area that is displayed in the zoom window.
Parameter:
<Time> *RST: 0
Std.-einheit: s
TIMebase:ZOOM:POSition <Position>
Defines the position of the zoom window in the upper window.
Parameter:
<Position> Bereich: Depends on the zoom time base, from nearly 0 to
100 % for large zoom.
*RST: 50
Std.-einheit: %
15.6.2 Mathematik
Beachten Sie neben den unten beschriebenen Befehlen auch folgende Befehle:
●
CALCulate:QMATh:DATA? auf Seite 382
●
CALCulate:QMATh:DATA:HEADer? auf Seite 382
●
CALCulate:QMATh:DATA:XINCrement? auf Seite 385
●
CALCulate:QMATh:DATA:XORigin? auf Seite 385
●
CALCulate:QMATh:DATA:YINCrement? auf Seite 386
●
CALCulate:QMATh:DATA:YORigin? auf Seite 386
●
CALCulate:QMATh:DATA:YRESolution? auf Seite 387
CALCulate:QMATH:STATe.............................................................................................. 303
CALCulate:QMATh:SOURce<m>.....................................................................................303
CALCulate:QMATh:OPERation........................................................................................304
CALCulate:QMATh:POSition........................................................................................... 304
CALCulate:QMATh:SCALe..............................................................................................304
CALCulate:QMATH:STATe <State>
Activates the mathematics function and displays the resulting math waveform.
Parameter:
<State> ON | OFF
CALCulate:QMATh:SOURce<m> <Source>
Defines the first and the second source for the mathematical operation (operands). The
sources can be any active analog channel.
Messkurvenanalyse
