5. FASTENING SETTING mode (Type S)
5-26
●Setting the detail of the HIGH SPEED
Following items are set up in the detail setting of the HIGH SPEED. Help windows of each item are displayed
on the bottom of the screen.
For more details, refer to the USER’S MANUAL.
Figure 5.3-10 DETAIL SETTING SCREEN OF HIGH SPEED
Input the value using numeric input keys and press EXEC. Press QUIT to cancel all new settings.
The contents of the value inputted on this screen are written to the NUTRUNNER when EXEC is pressed on
the Figure 5.3-6 SELECT PROGRAM SETTING SCREEN.
ITEM CONTENTS NOTE
Speed[rpm] The target constant speed is set.
Acceleration
(Deceleration)
The acceleration (or deceleration)
the set speed.
Range 1〜1000
0002
Table 5.3-4 SETTING ITEMS OF HIGH SPEED SELECT PROGRAM SETTING
