5. FASTENING SETTING mode (Type S)
5-32
●Setting the detail of the TIME DELAY
Following item is set up in the detail setting of the TIME DELAY. Help window of the item is displayed on the
bottom of the screen.
For more details, refer to the USER’S MANUAL.
Figure 5.3-16 DETAIL SETTING SCREEN OF TIME DELAY
Input the value using numeric input keys and press EXEC. Press QUIT to cancel all new settings.
The contents of the value inputted on this screen are written to the NUTRUNNER when EXEC is pressed on
the Figure 5.3-6 SELECT PROGRAM SETTING SCREEN.
ITEM CONTENTS NOTE
Stepping Time[sec] Program stop time (0 - 25.5 second) is set.
Table 5.3-10 SETTING ITEM OF TIME DELAY PARAMETER SELECT PROGRAM SETTING
