4.103
Date Code 20150130 Instruction Manual SEL-787 Relay
Protection and Logic Functions
Front-Panel Settings (SET F Command)
Figure 4.75 Front-Panel Display for an Analog Entry in the
Name String Only
Name and Alias
For a more descriptive name of the Relay Word bit, enter the Relay Word bit
in the Name String, and an alias name in User Text and Formatting String.
Table 4.58 shows a Boolean entry in the Name and Alias Strings (DP01) and
an entry in the Name and User Text and Formatting Strings (DP02), using the
SET F command as follows:
Figure 4.76 shows the front-panel display for the entry in Table 4.58. Input
IN101 is deasserted in this display (0), and the display changes to
INPUT
IN101=1
when Input IN101 asserts.
Figure 4.76 Front-Panel Display for an Entry in (a) Boolean Name and
Alias Strings and (b) Analog Name and User Text and Formatting Strings
If the engineering units are set, then the front-panel display shows the
engineering units. For example, in the Group setting example, we set
AI301EU to degrees C. With this setting, the front-panel display looks as
shown in Figure 4.77.
Figure 4.77 Front-Panel Display for an Entry in (a) Boolean Name and Alias
Strings and (b)AnalogName,UserTextandFormattingStrings,
and Engineering Units
For fixed text, enter a 1 in the Name String, then enter the fixed text as the
alias text. For example, to display the word DEFAULT and SETTINGS on two
different lines, use a display point for each word, i.e., DP01 = 1,“DEFAULT”
and DP02 = 1,“SETTINGS.” Table 4.59 shows other options and front-panel
displays for the User Text and Formatting settings.
AI301
5.36 mA
DP01 := RID, “{16}”
? IN101,"INPUT IN101:" <Enter>
DP02 := TID, “{16}”
? AI301,TEMPERATURE: <Enter>
Table 4.58 Entry in the Name String and the Alias Strings
Name Alias Set String Clear String
IN101 INPUT IN101 — —
AI301 TEMPERATURE — —
INPUT IN101:=0
TEMPERATURE:
0.024 mA
(a) Boolean
(b) Analog
INPUT IN101:=0
TEMPERATURE:
0.024 degree C
(a) Boolean
(b) Analog
