7.19
Date Code 20150130 Instruction Manual SEL-787 Relay
Communications
SEL ASCII Protocol and Commands
The => prompt indicates the relay is now in Access Level 1.
If the entered password is incorrect, the relay prompts you for the password
again (
Password: ?). The relay prompts for the password as many as three
times. If the requested password is incorrectly entered three times, the relay
pulses the SALARM Relay Word bit for one second and remains at Access
Level 0 (= prompt).
Access Level Attempt (Password Not Required). Assume the following
conditions:
➤ Access Level 1 password is disabled.
➤ Access Level is 0.
At the Access Level 0 prompt, enter the ACC command:
Because the password is disabled, the relay does not prompt you for a
password and goes directly to Access Level 1. The relay responds with the
following:
The
=> prompt indicates the relay is now in Access Level 1.
The two previous examples demonstrate going from Access Level 0 to
Access Level 1. The procedure to go from Access Level 1 to Access Level 2
with the 2AC command entered at the access level screen prompt is similar.
Access Level C can be accessed from Access Level 2 with the CAL
command. The relay pulses the SALARM Relay Word bit for one second after
a successful Level 2 or Level C access, or if access is denied.
ANALOG Command
Use the ANA command to test an analog output by temporarily assigning a
value to an analog output channel (see Table 7.8 for the command description
and Table 7.9 for the format). After entering the ANA command, the device
suspends normal operation of the analog output channel and scales the output
to a percentage of full scale. After assigning the specified value for the
specified time, the device returns to normal operation.
Entering any character (including pressing the space key) ends the command
before reaching the specified interval completion. You can test the analog
output in one of the following two modes:
➤ Fixed percentage: Outputs a fixed percentage of the signal for a
specified duration
➤ Ramp: Ramps the output from minimum to maximum of full
scale over the time specified
=ACC <Enter>
[RID Setting] Date: mm/dd/yyyy Time: hh:mm:ss.sss
[TID Setting] Time Source: external
Level 1
=>
Table 7.8 ANALOG Command
Command Description Access Level
ANA c p t Temporarily assigns a value to an analog output channel. 2
