DNP3 Communications
DNP3 Documentation
IBW1_MAG, ICW1_MAG, and IGW1_MAG together in the custom map. If
points are not grouped together, they might not come from the same data sample.
The following example describes how to create a custom DNP3 map by point
type. The example demonstrates the SEL ASCII command SET DNP for each
point type, but the entire configuration may be completed without saving
changes between point types. To do this, you simply continue entering data
and save the entire map at the end. Alternately, you can use
ACSELERATOR
QuickSet to simplify custom data map creation.
Consider a case where you want to set the AI points in a map, as shown in
Table D.13.
To set these points as part of custom map 1, you can use the command SET
DNP 1 AI_00 TERSE <Enter> command as shown in Figure D.5.
Table D.13 Sample Custom DNP3 AI Map
Desired
Point
Index
Description Label Scaling Dead Band
0 Winding 1, IA magnitude IAW1_MAG default default
1 Winding 1, IB magnitude IBW1_MAG default default
2 Winding 1, IC magnitude ICW1_MAG default default
3 Winding 2, IA magnitude IAW2_MAG default default
4 3-Phase Real Power P 5 default
5 AB Phase-to-Phase Voltage Magnitude VAB_MAG default default
6 AB Phase-to-Phase Voltage Angle VAB_ANG 1 15
7FrequencyFREQ.011
=>>SET DNP 1 AI_00 TERSE <Enter>
Analog Input Map
DNP Analog Input Label Name (23 characters)
AI_00 := NA
? > IAW1_MAG <Enter>
AI_01 := NA
? > IBW1_MAG <Enter>
AI_02 := NA
? > ICW1_MAG <Enter>
AI_03 := NA
? > IAW2_MAG <Enter>
AI_04 := NA
? > P:5 <Enter>
AI_05 := NA
? > VAB_MAG <Enter>
AI_06 := NA
? > VAB_ANG:1:15 <Enter>
AI_07 := NA
? > FREQ:.01:1 <Enter>
AI_08 := NA
? > end <Enter>
Save changes (Y/N) ? Y <Enter>
=>>
Figure D.5 Sample Custom DNP3 AI Map Settings
