Sel SEL-787 - Table F.13 Logical Device: MET (Metering)

F.21
Date Code 20150130 Instruction Manual SEL-787 Relay
IEC 61850 Communications
Logical Nodes
Table F.13 shows the LN associated with measuring elements defined as
Logical Device MET.
W1CSWI1 OpCls.general CC1 Breaker1 close control
W1CSWI1 OpOpn.general OC1 Breaker1 open control
W1CSWI1 Pos.stVal 52A1?1:2
b
Breaker1 position
(52A = false, breaker opened; 52A = true, breaker closed)
W1XCBR1 BlkCls.stVal 0 Breaker close blocking not configured by default
W1XCBR1 BlkOpn.stVal 0 Breaker open blocking not configured by default
W1XCBR1 CBOpCap.stVal None Breaker physical operation capabilities not known to relay
W1XCBR1 Loc.stVal 0 Breaker local control status not configured by default
W1XCBR1 OpCnt.stVal 0 Breaker operation counts not available
W1XCBR1 Pos.stVal 52A1?1:2
b
Breaker1 position
(52A = false, breaker opened; 52A = true, breaker closed)
W2CSWI2 OpCls.general CC2 Breaker2 close control
W2CSWI2 OpOpn.general OC2 Breaker2 open control
W2CSWI2 Pos.stVal 52A2?1:2
b
Breaker2 position
(52A = false, breaker opened; 52A = true, breaker closed)
W2XCBR2 BlkCls.stVal 0 Breaker close blocking not configured by default
W2XCBR2 BlkOpn.stVal 0 Breaker open blocking not configured by default
W2XCBR2 CBOpCap.stVal None Breaker physical operation capabilities not known to relay
W2XCBR2 Loc.stVal 0 Breaker local control status not configured by default
W2XCBR2 OpCnt.stVal 0 Breaker operation counts not available
W2XCBR2 Pos.stVal 52A2?1:2
b
Breaker2 position
(52A = false, breaker opened; 52A = true, breaker closed)
a
Writing a 0 to WnCSWIn.CO.Pos.Oper.ctlVal (n = 1, 2) will cause OCn to assert and writing any other value will cause CCn to assert.
b
If breaker/contactor is closed, value = 10(2); if breaker/contactor is opened, value = 01(1).
Table F.12 Logical Device: PRO (Protection) (Sheet 7 of 7)
Logical Node Attribute Data Source Comment
Table F.13 Logical Device: MET (Metering) (Sheet 1 of 5)
Logical Node Attribute Data Source Comment
Functional Constraint = DC
DevIDLPHD1 PhyNam.model PARTNO Part number
Functional Constraint = MX
a b
METMDST1 DmdA.nseq.instCVal.mag.f 3I2D Negative-sequence current demand
METMDST1 DmdA.phsA.instCVal.mag.f IAD Phase-A current demand
METMDST1 DmdA.phsB.instCVal.mag.f IBD Phase-B current demand
METMDST1 DmdA.phsC.instCVal.mag.f ICD Phase-C current demand
METMDST1 DmdA.res.instCVal.mag.f IGD Residual current demand
METMDST1 DmdVArh.instMag.f MVARHP Reactive energy, 3-phase positive
METMDST1 DmdWh.instMag.f MWHP Real energy, 3-phase positive
METMDST1 PkDmdA.nseq.instCVal.mag.f 3I2PD Negative-sequence current peak demand
METMDST1 PkDmdA.phsA.instCVal.mag.f IAPD Phase-A current peak demand
