7.23
Date Code 20150130 Instruction Manual SEL-787 Relay
Communications
SEL ASCII Protocol and Commands
For example, use the following command to set Remote bit RB05:
COPY Command
Use the COPY j k command (see Table 7.13) to copy the settings of settings
Group j to the settings of settings Group k. The settings of settings Group j
effectively overwrite the settings of settings Group k. Parameters j and k can
be any available settings group number 1 through 4.
For example when you enter the COPY 1 3 command, the relay responds,
Are
you sure (Y/N)?
Answer Y <Enter> (for yes) to complete copying. The
resultant settings in Group 3 are overwritten by the settings in Group 1 and
pulse the SALARM Relay Word bit.
COUNTER Command (Counter Values)
The device generates the values of the 32 counters in response to the COU
command (see Table 7.14).
DATE Command (View/Change Date)
Use the DATE command (see Table 7.15) to view and set the relay date.
The relay can overwrite the date entered by using other time sources such as
IRIG. Enter the DATE command with a date to set the internal clock date.
Table 7.12 Three Remote Bit States
Subcommand Description Access Level
S Set Remote bit (ON position) 2
C Clear Remote bit (OFF position) 2
P Pulse Remote bit for 1/4 cycle (MOMENTARY
position)
2
=>>CON RB05 S <Enter>
Table 7.13 COPY Command
Command Description Access Level
COPY j k
a
a
Parameters j and k are 1–4.
Copy settings in Group j to settings in Group k.2
Table 7.14 COUNTER Command
Command Description Access Level
COU n Display current state of device counters n times, with a
1/2-second delay between each display
1
Table 7.1 5 D a te Co m m a n d
Command Description Access Level
DATE Display the internal clock date. 1
DATE date Set the internal clock date
(DATE_F set to MDY, YMD, or DMY).
1
