Relay Word Bits
Overview
15
2_4HB1 2_4HB2 2_4HB3 2_4HBL 5HB1 5HB2 5HB3 5HBL
16
87BL1 87BL2 87BL3 87HB 87HR1 87HR2 87HR3 87HR
17
TH5 87AP 27P1 27P2 59P1 59P2 3PWR1P 3PWR2P
18
AMBALRM AMBTRIP OTHALRM OTHTRIP BFI1 BFI2 59Q1 59Q2
19
TRIP OUT101 OUT102 OUT103 OUT301 OUT302 OUT303 OUT304
20
OUT401 OUT402 OUT403 OUT404 OUT501 OUT502 OUT503 OUT504
21
IN101 IN102
a a a a a a
22
IN301 IN302 IN303 IN304 IN305 IN306 IN307 IN308
23
IN401 IN402 IN403 IN404 IN405 IN406 IN407 IN408
24
IN501 IN502 IN503 IN504 IN505 IN506 IN507 IN508
25
LINKA LINKB PMDOK SALARM WAR N I NG TSOK IRIGOK FAULT
26
COMMIDLE COMMLOSS COMMFLT CFGFLT LINKFAIL PASEL PBSEL LOP
27
FREQTRK ER
a a
RSTENRGY RSTMXMN RSTDEM RSTPKDEM
28
RTDFLT RTDIN TRGTR
a
RTDA DSABLSET RSTTRGT HALARM
29
RTD1A RTD1T RTD2A RTD2T RTD3A RTD3T RTD4A RTD4T
30
RTD5A RTD5T RTD6A RTD6T RTD7A RTD7T RTD8A RTD8T
31
RTD9A RTD9T RTD10A RTD10T RTD11A RTD11T RTD12A RTD12T
32
CLOSE1 CF1 CC1
aa
CLOSE2 CF2 CC2
33
SG1 SG2 SG3 SG4 TREA1 TREA2 TREA3 TREA4
34
OC1 OC2 TR1 TR2 TRXFMR TRIP1 TRIP2 TRIPXFMR
35
CL1 CL2 ULTRIP1 ULTRIP2 ULTRXFMR ULCL1 ULCL2 PMTRIG
36
DNAUX1 DNAUX2 DNAUX3 DNAUX4 DNAUX5 DNAUX6 DNAUX7 DNAUX8
37
DNAUX9 DNAUX10 DNAUX11 RELAY_EN
a
INR1 INR2 INR3
38
PB01 PB02 PB03 PB04 PB01_PUL PB02_PUL PB03_PUL PB04_PUL
39
PB1A_LED PB1B_LED PB2A_LED PB2B_LED PB3A_LED PB3B_LED PB4A_LED PB4B_LED
40
aa
T01_LED T02_LED T03_LED T04_LED T05_LED T06_LED
41
PHDEM 3I2DEM GNDEM
a a
TFLTALA TFLTALB TFLTALC
42
LB01 LB02 LB03 LB04 LB05 LB06 LB07 LB08
43
LB09 LB10 LB11 LB12 LB13 LB14 LB15 LB16
44
LB17 LB18 LB19 LB20 LB21 LB22 LB23 LB24
45
LB25 LB26 LB27 LB28 LB29 LB30 LB31 LB32
46
RB01 RB02 RB03 RB04 RB05 RB06 RB07 RB08
47
RB09 RB10 RB11 RB12 RB13 RB14 RB15 RB16
48
RB17 RB18 RB19 RB20 RB21 RB22 RB23 RB24
49
RB25 RB26 RB27 RB28 RB29 RB30 RB31 RB32
50
SV01 SV02 SV03 SV04 SV05 SV06 SV07 SV08
51
SV01T SV02T SV03T SV04T SV05T SV06T SV07T SV08T
52
SV09 SV10 SV11 SV12 SV13 SV14 SV15 SV16
53
SV09T SV10T SV11T SV12T SV13T SV14T SV15T SV16T
54
SV17 SV18 SV19 SV20 SV21 SV22 SV23 SV24
Table J.1 SEL-787 Relay Wo rd Bits (Sheet 2 of 4)
Bit/
Row
Relay Word Bits
7 6 5 4 3 2 1 0
