SEL-787 Relay Instruction Manual Date Code 20150130
Introduction and Specifications
Getting Started
Checking
Relay Status
Use the STA serial port command to view the SEL-787 operational status.
Analog channel dc offset and monitored component status are listed in the
status report depicted in Figure 1.2.
If a communications card with the DeviceNet protocol is present, the status
report depicted in Figure 1.3 applies. If a communications card with Modbus
RTU protocol is present, the status report depicted in Figure 1.2 applies.
Table 1.1 SEL-787 Serial Port Settings
Description Setting Label Default Value
SPEED SPEED 9600
DATA BITS BITS 8
PARITY PARITY N
STOP BITS STOP 1
PORT TIMEOUT T_OUT 5
HWDR HAND-
SHAKING
RTSCTS N
=>>STA <Enter>
SEL-787 Date: 06/28/2011 Time: 11:00:07.626
TRNSFRMR RELAY Time Source: Internal
Serial Num = 12345678910111
FID = SEL-787-R206-V0-Z003001-D20110610 CID = C351
PART NUM = 0787EX1B0X9X7585063X
SELF TESTS (W=Warn)
FPGA GPSB HMI RAM ROM CR_RAM NON_VOL CLOCK CID_FILE +0.9V +1.2V
OK OK OK OK OK OK OK OK OK 0.90 1.20
+1.5V +1.8V +2.5V +3.3V +3.75V +5.0V -1.25V -5.0V BATT
1.49 1.81 2.51 3.33 3.74 4.96 -1.25 -4.96 3.02
Option Cards
CARD_C CARD_D CARD_E CURRENT
OK OK OK OK
Offsets
IAW1 IBW1 ICW1 IAW2 IBW2 ICW2 IN VA VB VC
0 0 0 0 0 0 0 0 0 0
Relay Enabled
=>>
Figure 1.2 STA Command Response—No DeviceNet Communications Card or
EIA-232/EIA-485 Communications Card
NOTE: See Step 12 on page 2.11 for
information about the part number
displayed.
