Protection and Logic Functions
Front-Panel Settings (SET F Command)
Enter any of the Relay Word bits (or combinations of Relay Word bits) as
conditions in the Tn_LED SEL
OGIC control equation settings. When these
Relay Word bits assert, the corresponding LED also asserts.
Pushbutton LEDs
Enter any of the Relay Word bits (or combinations of Relay Word bits) as
conditions in the PBp_LED (p = 1A, 1B,…4A, 4B) SEL
OGIC control equation
settings. When these Relay Word bits assert, the corresponding LED also
asserts. Table 4.61 shows the setting prompts, settings ranges, and default
settings for the LEDs.
Table 4.60 Target LED Settings
Setting Prompt Setting Range Setting Name := Factory Default
TRIP LATCH T_LED Y, N T01LEDL := Y
LED1 EQUATION SEL
OGIC T01_LED := 87U OR 87R
TRIP LATCH T_LED Y, N T02LEDL := Y
LED2 EQUATION SEL
OGIC T02_LED := ORED50T
TRIP LATCH T_LED Y, N T03LEDL := Y
LED3 EQUATION SEL
OGIC T03_LED := ORED51T
TRIP LATCH T_LED Y, N T04LEDL := Y
LED4 EQUATION SEL
OGIC T04_LED := 27P1T OR 27P2T OR
59P1T OR 59P2T OR 59Q1T OR
59Q2T
TRIP LATCH T_LED Y, N T05LEDL := Y
LED5 EQUATION SEL
OGIC T05_LED := 81D1T OR 81D2T OR
81D3T OR 81D4T
TRIP LATCH T_LED Y, N T06LEDL := Y
LED6 EQUATION SEL
OGIC T06_LED := 24D1T OR 24C2T
Table 4.61 Pushbutton LED Settings
Setting Prompt Setting Range Setting Name := Factory Default
PB1A_LED EQUATION SELOGIC PB1A_LED := NOT LT01 OR SV01 AND
NOT SV01T AND SV05T
PB1B_LED EQUATION SEL
OGIC PB1B_LED := LT01 OR SV01 AND NOT
SV01T AND SV05T
PB2A_LED EQUATION SEL
OGIC PB2A_LED := NOT LT02 OR SV02 AND
NOT SV02T AND SV05T AND PB02
PB2B_LED EQUATION SEL
OGIC PB2B_LED := LT02 OR SV02 AND NOT
SV02T AND SV05T AND PB02
PB3A_LED EQUATION SEL
OGIC PB3A_LED := 52A1 OR (SV03 AND
SV05T AND NOT SV03T AND NOT LT02)
PB3B_LED EQUATION SEL
OGIC PB3B_LED := 52A2 OR (SV03 AND
SV05T AND NOT SV03T AND LT02)
PB4A_LED EQUATION SEL
OGIC PB4A_LED := NOT 52A1 OR (SV04
AND SV05T AND NOT SV04T AND
NOT LT02)
PB4B_LED EQUATION SEL
OGIC PB4B_LED := NOT 52A2 OR (SV04 AND
SV05T AND NOT SV04T AND LT02)
