SEL-787 Relay Instruction Manual Date Code 20150130
PC Software
Settings
Create a New Database, Copy an Existing Database
To create and copy an existing database of devices to a new database:
Step 1. Click File > Database Manager, and select the New button.
ACSELERATOR QuickSet prompts you for a file name.
Step 2. Type the new database name (and location if the new location
differs from the existing one), and click Save.
ACSELERATOR
QuickSet displays the message
Settings [path and
filename] was successfully created
.
Step 3. Click OK.
To copy an exiting database of devices to a new database:
Step 1. Click File > Database Manager, and select the Copy/Move
Settings Between Databases tab in the Database Manager
dialog box.
ACSELERATOR QuickSet opens the last active database and
assigns it as Settings Database A.
Step 2. Click the Settings Database B button;
ACSELERATOR
QuickSet prompts you for a file location.
Step 3. Type a new database name, click the Open button.
Settings
ACSELERATOR QuickSet offers the capability of creating settings for one or
more SEL-787 relays. Store existing relay settings downloaded from SEL-787
relays with
ACSELERATOR QuickSet, creating a library of relay settings, then
modify and upload these settings from the settings library to an SEL-787.
ACSELERATOR QuickSet makes setting the relay easy and efficient. However,
you do not have to use
ACSELERATOR QuickSet to configure the SEL-787;
you can use an ASCII terminal or a computer running terminal emulation
software.
ACSELERATOR QuickSet provides the advantages of rules-based
settings checks, SEL
OGIC
®
control equation Expression Builder, operator
control and metering HMI, event analysis, and help.
Settings Editor
The Settings Editor shows the relay settings in easy-to-understand categories.
The SEL-787 settings structure makes setting the relay easy and efficient.
Settings are grouped logically, and relay elements that are not used in the
selected protection scheme are not accessible. For example, if there is only
one analog card installed in the relay, you can access settings for this one card
only. Settings for the other slots are dimmed (grayed) in the
ACSELERATOR
QuickSet menus.
ACSELERATOR QuickSet shows all of the settings categories
in the settings tree view. The settings tree view remains constant whether
settings categories are enabled or disabled. However, any disabled settings are
dimmed when accessed by clicking an item in the tree view.
Settings Menu
ACSELERATOR QuickSet uses a database to store and manage SEL relay
settings. Each unique relay has its own record of settings. Use the File menu
to Open an existing record, create and open a New record, or Read relay
settings from a connected SEL-787 and then create and open a new record.
Use Tools menu to Convert and open an existing record. The record will be
opened in the Setting Editor as a Setting Form (template) or in Editor
Mode.
