9.9
Date Code 20150130 Instruction Manual SEL-787 Relay
Analyzing Events
Event Reporting
previous (see Figure 9.4 and Figure 9.5). These currents are listed at the end
of the event report in the event summary. If the trigger row (
>) and the
maximum phase current row (
*) are the same row, the * symbol takes
precedence.
=>>EVE <Enter>
SEL-787 Date: 02/14/2008 Time: 13:09:57.353
TRNSFRMR RELAY
Serial Number=000000000000000
FID=SEL-787-X122HR-V0-Z001001-D20080212 CID=26FF
O
I u
n t
Currents (A Pri) Voltages (V Pri) 1 13
IAW1 IBW1 ICW1 IAW2 IBW2 ICW2 IN VAB VBC VCA Freq 2 2
[1]
-54.5 206.0 -150.5 580.0-2085.0 1460.0 -0.6 12582 -10400 -2182 60.03 . ..
-206.5 56.0 153.0 2055.0 -505.0-1560.0 0.0 4900 8612 -13512 60.03 . ..
54.0 -206.5 149.5 -590.0 2080.0-1465.0 0.0 -12584 10398 2186 60.03 . ..
206.0 -56.5 -153.5-2060.0 495.0 1555.0 -1.2 -4895 -8616 13511 60.03 . ..
[2]
-54.5 206.0 -150.5 590.0-2085.0 1460.0 -1.2 12586 -10391 -2195 60.02 . ..
-206.5 55.5 153.5 2050.0 -500.0-1560.0 1.2 4886 8623 -13510 60.02 . ..
54.5 -206.5 149.5 -590.0 2080.0-1460.0 0.0 -12590 10390 2201 60.02 . ..
206.0 -56.0 -154.0-2060.0 495.0 1555.0 -1.8 -4883 -8626 13508 60.02 . ..
[3]
-55.5 206.0 -150.0 585.0-2085.0 1455.0 -0.6 12590 -10384 -2207 60.03 . ..
-206.5 55.5 153.5 2050.0 -500.0-1560.0 1.2 4878 8632 -13510 60.03 . ..
50.0 -207.0 149.5 -595.0 2080.0-1460.0 0.0 -12594 10380 2214 60.03 . ..
294.0 -55.5 -154.0-2055.0 495.0 1560.0 -1.8 -4872 -8636 13508 60.03 . ..
[4]
-89.0 206.5 -150.0 590.0-2085.0 1450.0 -0.6 12595 -10375 -2220 60.02 . ..
-438.5 55.0 153.5 2055.0 -500.0-1565.0 0.6 4864 8644 -13507 60.02 . ..
131.5 -207.0 149.5 -595.0 2080.0-1455.0 0.0 -12599 10370 2228 60.02 . ..
493.5 -55.5 -154.5-2060.0 490.0 1560.0 -1.2 -4858 -8647 13505 60.02 . ..
[5]
-132.5 206.5 -150.0 590.0-2085.0 1450.0 -0.6 12600 -10363 -2237 60.03 . ..
-494.0 55.0 154.0 2055.0 -495.0-1560.0 0.6 4852 8652 -13504 60.03 . ..
132.0 -207.0 149.0 -600.0 2080.0-1460.0 0.0 -12604 10361 2243 60.03 . ..
493.5 -55.5 -154.5-2060.0 485.0 1560.0 -1.2 -4848 -8654 13502 60.03>. ..
[6]
-133.0 207.0 -149.5 595.0-2085.0 1455.0 -0.6 12607 -10358 -2249 60.03 . .*
-494.0 54.5 154.0 2050.0 -490.0-1565.0 0.0 4838 8663 -13501 60.03 . .*
132.0 -207.5 148.5 -600.0 2080.0-1460.0 0.0 -12611 10356 2255 60.03 . .*
493.5 -55.0 -154.0-2055.0 485.0 1560.0 -1.2 -4832 -8668 13500 60.03 . .*
[7]
-133.0 207.0 -149.5 595.0-2085.0 1450.0 -0.6 12611 -10348 -2263 60.02 . .*
-494.0 54.5 154.0 2050.0 -490.0-1570.0 0.6 4826 8674 -13500 60.02 . .*
133.0 -207.5 149.0 -600.0 2080.0-1450.0 0.6 -12613 10344 2269 60.02 . .*
493.0 -54.5 -154.5-2055.0 485.0 1560.0 -1.2 -4819 -8677 13496 60.02 . .*
[8]
-133.5 207.0 -149.5 600.0-2085.0 1450.0 -1.2 12614 -10340 -2274 60.03 . .*
-493.5 54.0 154.0 2050.0 -490.0-1565.0 0.6 4812 8684 -13496 60.03 . .*
133.0 -207.0 149.5 -600.0 2085.0-1455.0 0.0 -12617 10337 2280 60.03 . .*
493.5 -55.5 -154.5-2060.0 480.0 1560.0 -1.2 -4808 -8688 13496 60.03 . .*
[9]
-134.0 206.5 -149.5 595.0-2085.0 1450.0 -0.6 12618 -10330 -2288 60.02 . .*
-493.5 54.5 154.5 2050.0 -485.0-1570.0 0.6 4802 8694 -13496 60.02 . .*
133.5 -207.5 148.5 -605.0 2080.0-1455.0 0.0 -12623 10327 2296 60.02 . .*
493.0 -55.0 -155.0-2055.0 480.0 1565.0 -1.8 -4798 -8698 13495 60.02 . .*
[10]
-134.5 207.0 -149.5 600.0-2090.0 1445.0 -0.6 12625 -10322 -2303 60.03 . .*
-494.0 54.0 154.5 2050.0 -485.0-1575.0 0.6 4789 8705 -13494 60.03 . .*
134.5 -207.5 149.0 -605.0 2085.0-1450.0 0.0 -12629 10319 2310 60.03 . .*
493.5 -54.5 -155.0-2060.0 480.0 1570.0 -0.6 -4784 -8708 13493 60.03 . .*
[11]
-135.5 207.0 -149.0 605.0-2090.0 1440.0 -1.2 12629 -10313 -2316 60.03 . .*
-493.5 53.5 154.5 2050.0 -480.0-1575.0 0.0 4776 8714 -13490 60.03 . .*
135.0 -207.5 148.5 -605.0 2085.0-1450.0 0.6 -12634 10312 2322 60.03 . .*
492.5 -54.0 -155.5-2055.0 475.0 1570.0 -1.2 -4771 -8718 13489 60.03 . .*
[12]
-135.5 207.0 -148.5 600.0-2090.0 1440.0 -1.2 12635 -10306 -2329 60.03 . .*
-493.0 53.5 154.5 2050.0 -480.0-1575.0 0.6 4764 8725 -13489 60.03 . .*
135.5 -207.5 148.0 -605.0 2085.0-1445.0 0.0 -12637 10303 2334 60.03 . .*
492.5 -54.0 -155.5-2055.0 470.0 1575.0 -1.8 -4760 -8729 13489 60.03 . .*
Figure 9.3 Example Standard 15-Cycle Analog Event Report 1/4-Cycle Resolution (Sheet 1 of 4)
Date and Time of Event
Optional Voltage Card Required
One Cycle of Data
