9.10
SEL-787 Relay Instruction Manual Date Code 20150130
Analyzing Events
Event Reporting
[13]
-136.0 206.5 -149.0 605.0-2090.0 1440.0 -1.2 12637 -10298 -2339 60.03 . .*
-493.0 53.5 155.0 2050.0 -475.0-1580.0 1.2 4753 8736 -13489 60.03 . .*
136.0 -207.5 148.5 -615.0 2080.0-1445.0 0.0 -12641 10295 2346 60.03 . .*
492.5 -54.5 -156.0-2055.0 475.0 1570.0 -1.2 -4747 -8738 13486 60.03 . .*
[14]
-136.5 207.0 -148.5 610.0-2090.0 1445.0 -0.6 12642 -10288 -2354 60.02 . .*
-493.5 53.5 155.5 2050.0 -480.0-1580.0 0.0 4741 8742 -13483 60.02*. .*
136.0 -207.5 148.0 -615.0 2085.0-1450.0 0.0 -12646 10285 2360 60.02 . .*
492.5 -54.0 -156.0-2050.0 465.0 1575.0 -0.6 -4734 -8747 13481 60.02 . .*
[15]
-137.0 207.0 -148.0 610.0-2090.0 1440.0 -0.6 12647 -10279 -2368 60.03 . .*
-493.0 53.0 155.5 2045.0 -470.0-1580.0 0.0 4727 8754 -13481 60.03 . .*
136.5 -207.5 147.5 -615.0 2080.0-1440.0 0.0 -12650 10278 2372 60.03 . .*
492.0 -53.5 -155.5-2055.0 470.0 1575.0 -1.2 -4723 -8758 13481 60.03 . .*
Serial No = 000000000000000
FID = SEL-787-X122HR-V0-Z001001-D20080212 CID = 26FF
EVENT LOGS = 1
Event: Diff 87 Trip
Targets 11100000
Freq (Hz) 60.0
Winding One Current Mag
IAW1 IBW1 ICW1 IGW1
(A) 512.0 213.8 215.0 295.00
Winding Two Current Mag
IAW2 IBW2 ICW2 IGW2
(A) 2138.8 2144.4 2141.1 36.40
Neutral Current Mag
IN
(A) 0.60
Voltage Mag
VAB VBC VCA
(V) 13501 13500 13687
Global Settings
PHROT := ABC FNOM := 60 DATE_F := MDY
FAULT := ORED50P OR ORED51P OR TRIP
EMP := N TGR := 3
SS1 := 1
SS2 := 0
SS3 := 0
SS4 := 0
EPMU := N
52ABF := N BFD1 := 0.50 BFI1 := R_TRIG TRIP1 OR R_TRIG TRIPXFMR
BFD2 := 0.50 BFI2 := R_TRIG TRIP2 OR R_TRIG TRIPXFMR
THFLTD := OFF
IN101D := 10 IN102D := 10
RSTTRGT := 0
RSTENRGY:= 0
RSTMXMN := 0
RSTDEM := 0
RSTPKDEM:= 0
DSABLSET:= 0
Group Settings
RID := SEL-787
TID := TRNSFRMR RELAY
W1CT := WYE W2CT := WYE
CTR1 := 100 CTR2 := 1000 MVA := 50.0 ICOM := N
VWDG1 := 138.00 VWDG2 := 13.80
CTRN1 := 120 PTR := 120.00 VNOM := 13.80 DELTA_Y := DELTA
VIWDG := 2 SINGLEV := N
E87 := Y TAP1 := 2.09 TAP2 := 2.09
O87P := 0.30 87AP := 0.15 87AD := 5.0 SLP1 := 25
SLP2 := 50 IRS1 := 3.0
U87P := 10.0 PCT2 := 15 PCT4 := OFF PCT5 := 35
TH5P := OFF HRSTR := Y HBLK := N
REF1POL := OFF REF1TC := 1
50REF1P := 0.25
Figure 9.3 Example Standard 15-Cycle Analog Event Report 1/4-Cycle Resolution (Sheet 2 of 4)
Firmware Checksum Identifier
Firmware Identifier
