7.34
SEL-787 Relay Instruction Manual Date Code 20150130
Communications
SEL ASCII Protocol and Commands
PING Command
When you are setting up or testing substation networks, it is helpful to
determine if the network is connected properly and if the other devices are
powered up and configured properly. The PING command (Access Level 2)
allows a user of the relay to determine if a host is reachable across an IP
network and/or if the Ethernet port (Port 1) is functioning or configured
correctly. A typical PING command response is shown in Figure 7.19.
The command structure is:
PING x.x.x.x t
where:
x.x.x.x is the Host IP address and
‘t’ is the PING interval in seconds, with a 2 to 255 second range.
The default PING interval is one second when ‘t’ is not specified. The relay
sends ping messages to the remote node until you stop the PING test by
pressing the ‘Q’ key.
PULSE Command
Use the PULSE command (see Table 7.36) to pulse any of the relay control
outputs for a specified time. This function aids you in relay testing and
commissioning. When a PUL command is issued, the selected contact will
close or open depending on the output contact type (a or b). The PUL
command energizes the coil and does not have any effect if the coil is already
energized. The control outputs are OUTnnn, where nnn represents 101–103
(standard), 301–304 (optional), 401–404 (optional), or 501–504 (optional).
==>>PING 10.201.7.52 <Enter>
Press the Q key to end the ping test.
Pinging 10.201.7.52 every 1 second(s):
Reply from 10.201.7.52
Reply from 10.201.7.52
Reply from 10.201.7.52
Reply from 10.201.7.52
Reply from 10.201.7.52
Reply from 10.201.7.52
Ping test stopped.
Ping Statistics for 10.201.7.52
Packets: Sent = 7, Received = 6, Lost = 1
Duplicated = 0
==>>
Figure 7.19 PING Command Response
Table 7.36 PUL OUTnnn Command
Command Description Access Level
PUL OUTnnn
a
a
Parameter nnn is a control output number.
Pulse output OUTnnn for 1 second. 2
PUL OUTnnn s
b
b
Parameter s is time in seconds, with a range of 1–30.
Pulse output OUTnnn for s seconds. 2
NOTE: The PULSE command is
available when the breaker control
jumper on the main board is in the
ENABLED position.
