Sel SEL-787 - Table F.15 Logical Device: ANN (Annunciation)

F.26
SEL-787 Relay Instruction Manual Date Code 20150130
IEC 61850 Communications
Logical Nodes
Table F.15 shows the LN associated with annunciation elements defined as
Logical Device ANN.
Table F.15 Logical Device: ANN (Annunciation) (Sheet 1 of 3)
Logical Node Attribute Data Source Comment
Functional Constraint = DC
DevIDLPHD1 PhyNam.model PARTNO Part number
Functional Constraint = MX
a
AINCGGIO21 AnIn01.instMag.f–
AnIn04.instMag.f
AI301–AI304
b
Analog inputs (AI301 to AI304)—Slot C
AINDGGIO22 AnIn01.instMag.f–
AnIn04.instMag.f
AI401–AI404
b
Analog inputs (AI401 to AI404)—Slot D
AINEGGIO23 AnIn01.instMag.f–
AnIn04.instMag.f
AI501–AI504
b
Analog inputs (AI501 to AI504)—Slot E
MVGGIO12 AnIn01.instMag.f–
AnIn32.instMag.f
MV01–MV32
c
Math variables (MV01 to MV32)
SCGGIO20 AnIn01.instMag.f–
AnIn32.instMag.f
SC01–SC32
d
SELOGIC counters (SC01 to SC32)
Functional Constraint = ST
INAGGIO1 Ind01.stVal–Ind02.stVal IN101–IN102 Digital inputs (IN101 to IN102)—Slot A
INCGGIO13 Ind01.stVal–Ind08.stVal IN301–IN308
b
Digital inputs (IN301 to IN308)—Slot C
INDGGIO15 Ind01.stVal–Ind08.stVal IN401–IN408
b
Digital inputs (IN401 to IN408)—Slot D
INEGGIO17 Ind01.stVal–Ind08.stVal IN501–IN508
b
Digital inputs (IN501 to IN508)—Slot E
LBGGIO25 Ind01.stVal–Ind32.stVal LB01–LB32
e
Local bits (LB01 to LB32)
LTGGIO5 Ind01.stVal–Ind32.stVal LT01–LT32
f
Latch bits (LT01 to LT32)
MBOKGGIO26 Ind01.stVal ROKA Channel A, received data ok
MBOKGGIO26 Ind02.stVal RBADA Channel A, outage duration over threshold
MBOKGGIO26 Ind03.stVal CBADA Channel A, channel unavailability over threshold
MBOKGGIO26 Ind04.stVal LBOKA Channel A, looped back ok
MBOKGGIO26 Ind05.stVal ROKB Channel B, received data ok
MBOKGGIO26 Ind06.stVal RBADB Channel B, outage duration over threshold
MBOKGGIO26 Ind07.stVal CBADB Channel B, channel unavailability over threshold
MBOKGGIO26 Ind08.stVal LBOKB Channel B, looped back ok
MISCGGIO27 Ind01.stVal–Ind04.stVal SG1–SG4 Setting Group 1 to 4 selection
MISCGGIO27 Ind05.stVal HALARM Indication of a diagnostic failure or warning that warrants
an ALARM
MISCGGIO27 Ind06.stVal SALARM Indication of software or user activity that warrants an
ALARM
MISCGGIO27 Ind07.stVal WARNING Relay Word WARNING
MISCGGIO27 Ind08.stVal IRIGOK IRIG-B time synch input data are valid
MISCGGIO27 Ind09.stVal TSOK Time synchronization OK
MISCGGIO27 Ind10.stVal DST Daylight-Saving Time active
MISCGGIO27 Ind11.stVal LINKA Asserted when a valid link is detected on Port 1A
MISCGGIO27 Ind12.stVal LINKB Asserted when a valid link is detected on Port 1B
