Sel SEL-787 - Page 537

F.27
Date Code 20150130 Instruction Manual SEL-787 Relay
IEC 61850 Communications
Logical Nodes
MISCGGIO27 Ind13.stVal LINKFAIL Asserted when a valid link is not detected on the active
port(s)
MISCGGIO27 Ind14.stVal PASEL Asserted when Port 1A is active
MISCGGIO27 Ind15.stVal PBSEL Asserted when Port 1B is active
MISCGGIO27 Ind16.stVal COMMLOSS DeviceNet communication failure
MISCGGIO27 Ind17.stVal COMMFLT DeviceNet internal communication failure
MISCGGIO27 Ind18.stVal MATHERR Error in SEL Math computation
MISCGGIO27 Ind19.stVal–Ind32.stVal 0 Reserved for future use
OUTAGGIO2 Ind01.stVal–Ind03.stVal OUT101–OUT103 Digital outputs (OUT101 to OUT103)—Slot A
OUTCGGIO14 Ind01.stVal–Ind04.stVal OUT301–OUT304
b
Digital outputs (OUT301 to OUT304)—Slot C
OUTDGGIO16 Ind01.stVal–Ind04.stVal OUT401–OUT404
b
Digital outputs (OUT401 to OUT404)—Slot D
OUTEGGIO18 Ind01.stVal–Ind04.stVal OUT501–OUT504
b
Digital outputs (OUT501 to OUT504)—Slot E
PBLEDGGIO7 Ind01.stVal PB1A_LED Pushbutton PB1A LED
PBLEDGGIO7 Ind02.stVal PB1B_LED Pushbutton PB1B LED
PBLEDGGIO7 Ind03.stVal PB2A_LED Pushbutton PB2A LED
PBLEDGGIO7 Ind04.stVal PB2B_LED Pushbutton PB2B LED
PBLEDGGIO7 Ind05.stVal PB3A_LED Pushbutton PB3A LED
PBLEDGGIO7 Ind06.stVal PB3B_LED Pushbutton PB3B LED
PBLEDGGIO7 Ind07.stVal PB4A_LED Pushbutton PB4A LED
PBLEDGGIO7 Ind08.stVal PB4B_LED Pushbutton PB4B LED
PROGGIO24 Ind01.stVal REMTRIP Remote trip
PROGGIO24 Ind02.stVal ULTRIP1 Unlatch (auto reset) trip from SEL
OGIC equation
PROGGIO24 Ind03.stVal ULTRIP2 Unlatch (auto reset) trip from SEL
OGIC equation
PROGGIO24 Ind04.stVal ULTRXFMR Unlatch (auto reset) trip from SEL
OGIC equation
PROGGIO24 Ind05.stVal ULCL1 Unlatch close conditions SEL
OGIC Equation CL1 state
PROGGIO24 Ind06.stVal ULCL2 Unlatch close conditions SEL
OGIC Equation CL2 state
PROGGIO24 Ind07.stVal RTDT Asserts when any RTD trip is asserted
PROGGIO24 Ind08.stVal AMBTRIP Ambient temperature trip
PROGGIO24 Ind09.stVal OTHTRIP Other temperature trip
PROGGIO24 Ind10.stVal TH5T Fifth-harmonic alarm threshold exceeded for longer than
TH5D
PROGGIO24 Ind11.stVal TH5 Fifth-harmonic alarm threshold exceeded
PROGGIO24 Ind12.stVal RTDFLT Asserts when an open or short circuit condition is detected
on any enabled RTD input, or communication with the
external RTD module has been interrupted
PROGGIO24 Ind13.stVal PHDEM Phase current demand pickup
PROGGIO24 Ind14.stVal 3I2DEM Negative-sequence current demand pickup
PROGGIO24 Ind15.stVal GNDEM Zero-sequence current demand pickup
PROGGIO24 Ind16.stVal 50GREF1 Normalized residual current sensitivity threshold exceeded
PROGGIO24 Ind17.stVal 50NREF1 Neutral current sensitivity threshold exceeded
Table F.15 Logical Device: ANN (Annunciation) (Sheet 2 of 3)
Logical Node Attribute Data Source Comment
