DNP3 Communications
DNP3 Documentation
Default Data Map
The default data map is an automatically generated subset of the reference
map. All data maps are initialized to the default values, based on the SEL-787
part number. Table D.11 shows the SEL-787 default data map. If the default
maps are not appropriate, you can also use the custom DNP mapping
commands SET DNN and SHOW DNN to create the map required for your
application.
Analog Outputs
40, 41 GROUP Active Settings Group
NOOP No operation, no error
a
Valid Relay Word bits depend on the relay model.
b
Valid analog inputs depend on the relay model.
c
Refer to Default Analog Inputs for default analog input scaling and dead bands.
Table D.10 DNP3 Reference Data Map (Sheet 2 of 2)
Object Labels Description
Table D.11 DNP3 Default Data Map
Object Default Index Point Label
01, 02 0 ENABLED
1 TRIPXFMR
2TRIP1
3TRIP2
4STFAIL
5STSET
6 IN101
7 IN102
8–99 A portion of these binary inputs can have default values as
described in Default Binary Inputs on page D.20. Outside
that scope, they contain the value NA.
10, 12 0–31 RB01–RB32 Remote Bits
20, 22 0–31 NA
30, 32, 34 0 IAW1_MAG
1 IBW1_MAG
2 ICW1_MAG
3IGW1_MAG
4 IAW2_MAG
5 IBW2_MAG
6 ICW2_MAG
7IGW2_MAG
8IAVW1MAG
9IAVW2MAG
10 3I2W1MAG
11 3I2W1MAG
12–99 A portion of these analog inputs can have default values as
described in Default Analog Inputs on page D.20. Outside
that scope, they contain the value NA.
40, 41 0–31 NA
