A.8
SEL-787 Relay Instruction Manual Date Code 20150130
Firmware and Manual Versions
ICD File
The ICD revision number is after the R (e.g., 100) and the release date is after
the D. This revision number is not related to the relay firmware revision
number. The configVersion revision displays the ICD file version used to
create the CID file that is loaded in the relay.
The configVersion contains other useful information. The Z number consists
of six digits. The first three digits following the Z represent the minimum IED
firmware required to be used with the ICD (e.g., 209). The second three digits
represent the ICD ClassFileVersion (e.g., 004). The ClassFileVersion
increments when there is a major addition or change to the 61850
implementation of the relay.
Table A.5 lists the ICD file versions, a description of modifications, and the
instruction manual date code that corresponds to the versions. The most recent
version is listed first.
NOTE: The Z number
representation is implemented with
ICD File Revision R303. Previous ICD
File Revisions do not provide an
informative Z number.
Table A.5 SEL-787 ICD File Revision History
configVersion Summary of Revision
Relay
Firmware
Compatibility
ClassFile
Version
ACSELERATOR
Architect File
Description
Architect
Software
Version
Manual
Date
Code
ICD-787-R303-V0-
Z209004-D20140303
➤ Updated configVersion
for new format.
➤ Modified default MMS
Report and Dataset
names.
➤ Updated all Report
Control attributes.
➤ Corrected Report Control
rptID attributes to display
report name instead of
dataset name.
➤ Updated orCat control
instances to proprietary
node.
➤ Made correction per
KEMA
recommendations.
➤ Added new
P11APIOC19,
P11BPIOC20,
P11CPIOC21,
P21APIOC22,
P21BPIOC23,
P21CPIOC24,
P1APTOC8,
P1BPTOC9,
P1CPTOC10,
P2APTOC11,
P2BPTOC12,
P2CPTOC13,
REF1RPDIF6,
Q1TPTOV2,
Q2TPTOV3,
PWR1PDUP1,
PWR2PDUP2,
PWR1PDOP1,
PWR2PDOP2,
BFR1RBRF1, and
BFR2RBRF2 Logical
Nodes and attributes to
PRO LDevice.
R209 and higher 004
a
787 R209 and
above
1.1.145.0
and higher
20140714
