Sel SEL-787 - Table E.33 Modbus Register Labels for Use with SET M Command

E.22
SEL-787 Relay Instruction Manual Date Code 20150130
Modbus RTU Communications
Communications Protocol
Table E.33 Modbus Register Labels for Use With SET M Command (Sheet 3 of 3)
1052 SC19
1053 SC20
1054 SC21
1055 SC22
1056 SC23
1057 SC24
1058 SC25
1059 SC26
1060 SC27
1061 SC28
1062 SC29
1063 SC30
1064 SC31
1065 SC32
1066–1081
a
1082 NUMEVE
1083 EVESEL
1084 EVE_S
1085 EVEMN
1086 EVE_H
1087 EVE_D
1088 EVEMO
1089 EVE_Y
1090 EVE_TYPE
1091 EVE_TRGT
1092 EVE_IAW1
1093 EVE_IBW1
1094 EVE_ICW1
1095 EVE_IGW1
1096 EVE_IAW2
1097 EVE_IBW2
1098 EVE_ICW2
1099 EVE_IGW2
1100 EVE_IN
1101 EVE_VAB
1102 EVE_VBC
1103 EVE_VCA
1104 EVE_VG
1105 EVE_DY
1106 EVE_FREQ
1107 EVE_MAXA
1108 EVE_MAXO
1109 RES_1109
1110–1116
a
1117 TRIP_LO
1118 TRIP_HI
Register
Address
Label
1119 WARN_LO
1120 WA RN _ HI
1121–1125
a
1126 NUMRCV
1127 NUMOTH
1128 INVADR
1129 BADCRC
1130 UARTERR
1131 ILLFUNC
1132 ILLREG
1133 ILLWR
1134 BADPKTF
1135 BADPKTL
1136–1141
a
1142 ROW_0
1143 ROW_1
1144 ROW_2
1145 ROW_3
1146 ROW_4
1147 ROW_5
1148 ROW_6
1149 ROW_7
1150 ROW_8
1151 ROW_9
1152 ROW_10
1153 ROW_11
1154 ROW_12
1155 ROW_13
1156 ROW_14
1157 ROW_15
1158 ROW_16
1159 ROW_17
1160 ROW_18
1161 ROW_19
1162 ROW_20
1163 ROW_21
1164 ROW_22
1165 ROW_23
1166 ROW_24
1167 ROW_25
1168 ROW_26
1169 ROW_27
1170 ROW_28
1171 ROW_29
1172 ROW_30
1173 ROW_31
Register
Address
Label
1174 ROW_32
1175 ROW_33
1176 ROW_34
1177 ROW_35
1178 ROW_36
1179 ROW_37
1180 ROW_38
1181 ROW_39
1182 ROW_40
1183 ROW_41
1184 ROW_42
1185 ROW_43
1186 ROW_44
1187 ROW_45
1188 ROW_46
1189 ROW_47
1190 ROW_48
1191 ROW_49
1192 ROW_50
1193 ROW_51
1194 ROW_52
1195 ROW_53
1196 ROW_54
1197 ROW_55
1198 ROW_56
1199 ROW_57
1200 ROW_58
1201 ROW_59
1202 ROW_60
1203 ROW_61
1204 ROW_62
1205 ROW_63
1206 ROW_64
1207 ROW_65
1208 ROW_66
1209 ROW_67
1210 ROW_68
1211 ROW_69
1212 ROW_70
1213 ROW_71
1214 ROW_72
1215 ROW_73
1216 ROW_74
1217 ROW_75
1218 ROW_76
1219 ROW_77
Register
Address
Label
1220 ROW_78
1221 ROW_79
1222 ROW_80
1223 ROW_81
1224 ROW_82
1225 ROW_83
1226 ROW_84
1227 ROW_85
1228 ROW_86
1229 ROW_87
1230 ROW_88
1231 ROW_89
1232 ROW_90
1233 ROW_91
1234 ROW_92
1235 ROW_93
1236 ROW_94
1237 ROW_95
1238 ROW_96
1239 ROW_97
1240 ROW_98
1241 ROW_99
1242 ROW_100
1243 ROW_101
1244 ROW_102
1245 ROW_103
1246 ROW_104
1247 ROW_105
1248 ROW_106
1249 NA
a
All the reserved
registers between the
data areas in the map
may also be assigned
to the user registers
with a label RES_xxxx,
where xxxx is the
register number.
Register
Address
Label
