Installation
I/O Configuration
➤ Event Messenger
➤ C37.118 (Synchrophasor Data)
Port 1 (Ethernet) supports the following protocols:
➤ Modbus TCP/IP
➤ DNP3 LAN/WAN
➤ IEC 61850
➤ Simple Network Time Protocol (SNTP)
➤ FTP
➤ Telnet
Port 2 and Port 3 support the following protocols:
➤ Modbus RTU Slave
➤ SEL ASCII and Compressed ASCII
➤ SEL Fast Meter
➤ SEL Fast Operate
➤ SEL Fast SER
➤ SEL Fast Message Unsolicited Write
➤ SEL Settings File Transfer
➤ SEL MIRRORED BITS
®
(MBA, MBB, MB8A, MB8B, MBTA,
MBTB)
➤ Event Messenger
➤ DNP3 Slave Level 2
➤ C37.118 (Synchrophasor Data)
Communications Card
Either the DeviceNet (see Appendix G: DeviceNet Communications) or the
EIA-232/EIA-485 communications card is supported in Slot C. The EIA-232/
EIA-485 card provides one serial port with one of the following two serial
port interfaces:
➤ Port 4A, an isolated EIA-485 serial port interface
➤ Port 4C, nonisolated EIA-232 serial port interface, supporting the
+5 Vdc interface
Select either EIA-232 or EIA-485 functionality using the Port 4 Setting
COMM Interface. Table 2.3 shows the port number, interface, and type of
connector for the two protocols.
The communications card supports all of the following protocols:
➤ Modbus RTU Slave
➤ SEL ASCII and Compressed ASCII
➤ SEL Fast Meter
➤ SEL Fast Operate
➤ SEL Fast SER
Table 2.3 Communication Card Interfaces and Connectors
Port Interface Connectors
4A EIA-485 5-pin Euro
4C EIA-232 D-sub
