DNP3 Communications
DNP3 Documentation
You can also use the MAP DNP y s <Enter> command to display DNP3
maps, but the parameter y is the port number from 1 to 4. Because Port 1, the
Ethernet port, can support multiple DNP3 sessions, it may have a different
map assigned to each session selected by parameter s for sessions 1 to 3. See
Figure D.4 for an example of a MAP command that shows the same map as in
Figure D.3.
…
CO_29 := SC30
CO_30 := SC31
CO_31 := SC32
=>>
=>MAP DNP 1 1 <Enter>
SEL-787 Date: 02/14/2008 Time: 09:33:39
TRNSFRMR RELAY Time Source: Internal
Map 1
Transport TCP
Device IP Address 10.201.5.3
Master IP Address 10.200.0.139
Device DNP TCP and UDP Port 20000
Device DNP Address 15
Master DNP Address 0
Binary Inputs
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS SER TIMESTAMP
0 ENABLED 1 No
1 T01_LED 1 No
2 T02_LED 1 No
3 T03_LED 1 No
…
97 IN101 1 No
98 IN102 1 No
99 52A1 1 No
Binary Outputs
--------------------------------------------------------------------------------
INDEX POINT LABEL
0 RB01
1 RB02
2 RB03
…
29 RB30
30 RB31
31 RB32
Counters
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS DEADBAND
0 SC01 0 1
1 SC02 0 1
2 SC03 0 1
…
29 SC30 0 1
30 SC31 0 1
31 SC32 0 1
Figure D.4 Port MAP Command (Sheet 1 of 2)
Figure D.3 Sample Response to SHO DNP Command (Sheet 2 of 2)
