Sel SEL-787 - Table F.16 Logical Device: CFG (Configuration)

F.28
SEL-787 Relay Instruction Manual Date Code 20150130
IEC 61850 Communications
Logical Nodes
PROGGIO24 Ind18.stVal AMBALRM Ambient temperature alarm
PROGGIO24 Ind19.stVal OTHALRM Other temperature alarm
PROGGIO24 Ind20.stVal FREQTRK Frequency tracking enable bit
PROGGIO24 Ind21.stVal–Ind32.stVal 0 Reserved for future use
RMBAGGIO8 Ind01.stVal–Ind08.stVal RMB1A–RMB8A Receive M
IRRORED BITS (RMB1A to RMB8A)
RMBBGGIO10 Ind01.stVal–Ind08.stVal RMB1B–RMB8B Receive M
IRRORED BITS (RMB1B to RMB8B)
SVGGIO3 Ind01.stVal–Ind32.stVal SV01–SV32
g
SELOGIC variables (SV01 to SV32)
SVTGGIO4 Ind01.stVal–Ind32.stVal SV01T–SV32T
g
SELOGIC variable timers (SV01T to SV32T)
TLEDGGIO6 Ind01.stVal ENABLED ENABLED LED
TLEDGGIO6 Ind02.stVal TRIP_LED TRIP LED
TLEDGGIO6 Ind03.stVal–Ind08.stVal TLED_01–TLED_06 Target LEDs TLED_01 to TLED_06
TMBAGGIO9 Ind01.stVal–Ind08.stVal TMB1A–TMB8A Transmit M
IRRORED BITS (TMB1A to TMB8A)
TMBBGGIO11 Ind01.stVal–Ind08.stVal TMB1B–TMB8B Transmit M
IRRORED BITS (TMB1B to TMB8B)
VBGGIO19 Ind001.stVal–Ind128.stVal VB001–VB128 Virtual bits (VB001 to VB128)
Table F.15 Logical Device: ANN (Annunciation) (Sheet 3 of 3)
Logical Node Attribute Data Source Comment
Table F.16 Logical Device: CFG (Configuration)
Logical Node Attribute Data Source Comment
Functional Constraint = DC
DevIDLPHD1 PhyNam.model PARTNO Part number
DevIDLPHD1 PhyNam.serNum SER_NUM Serial number
LLN0 NamPlt.swRev FID Firmware revision
