F.25
Date Code 20150130 Instruction Manual SEL-787 Relay
IEC 61850 Communications
Logical Nodes
Table F.14 shows the LN associated with control elements defined as Logical
Device CON.
RMS1MMXU2 A1.phsC.instCVal.mag.f ICW1RMS Winding1 RMS current, C-phase, magnitude
RMS1MMXU2 A2.phsA.instCVal.mag.f IAW2RMS Winding2 RMS current, A-phase, magnitude
RMS1MMXU2 A2.phsB.instCVal.mag.f IBW2RMS Winding2 RMS current, B-phase, magnitude
RMS1MMXU2 A2.phsC.instCVal.mag.f ICW2RMS Winding2 RMS current, C-phase, magnitude
RMS2MMXU3 A.neut.instCVal.mag.f INRMS Neutral RMS current, magnitude
RMS2MMXU3 PhV.phsA.instCVal.mag.f VARMS RMS voltage, A-phase-to-neutral, magnitude
RMS2MMXU3 PhV.phsB.instCVal.mag.f VBRMS RMS voltage, B-phase-to-neutral, magnitude
RMS2MMXU3 PhV.phsC.instCVal.mag.f VCRMS RMS voltage, C-phase-to-neutral, magnitude
RMS2MMXU3 PPV.phsAB.instCVal.mag.f VABRMS RMS voltage, A-to-B-phase, magnitude
RMS2MMXU3 PPV.phsBC.instCVal.mag.f VBCRMS RMS voltage, B-to-C-phase, magnitude
RMS2MMXU3 PPV.phsCA.instCVal.mag.f VCARMS RMS voltage, C-to-A-phase, magnitude
THERMMTHR1 MaxAmbTmp.instMag.f RTDAMB
c
Ambient RTD temperature
THERMMTHR1 MaxOthTmp.instMag.f RTDOTHMX
c
Other maximum RTD temperature
THERMMTHR1 Tmp01.instMag.f–Tmp12.instMag.f RTD1 - RTD12
c
RTD1–RTD12 temperature
Functional Constraint = ST
THERMMTHR1 EEHealth.stVal RTDFLT?1:3
c
RTD input or communication status
a
MX values contain instantaneous attributes (instMag and instCVal), which are updated whenever the source updates and other
attributes which are only updated when the source goes outside the data sources dead band (mag and cVal). Only the
instantaneous values are shown in the table.
b
Data validity depend on the relay model and installed card options. Refer to Section 1: Introduction and Specifications for
different relay models and available card options. Refer to Section 5: Metering and Monitoring for the model dependent metering
quantities.
c
Valid data depend on E49RTD and RTD1LOC–RTD12LOC settings.
Table F.13 Logical Device: MET (Metering) (Sheet 5 of 5)
Logical Node Attribute Data Source Comment
Table F.14 Logical Device: CON (Remote Control)
Logical Node Status Control Relay Word Bit Comment
RBGGIO1 SPCSO01.stVal–
SPCSO08.stVal
SPCSO01.Oper.ctlVal–
SPCSO08.Oper.ctlVal
RB01–RB08 Remote Bits RB01–RB08
RBGGIO2 SPCSO09.stVal–
SPCSO16.stVal
SPCSO09.Oper.ctlVal–
SPCSO16.Oper.ctlVal
RB09–RB16 Remote Bits RB09–RB16
RBGGIO3 SPCSO17.stVal–
SPCSO24.stVal
SPCSO17.Oper.ctlVal–
SPCSO24.Oper.ctlVal
RB17–RB24 Remote Bits RB17–RB24
RBGGIO4 SPCSO25.stVal–
SPCSO32.stVal
SPCSO25.Oper.ctlVal–
SPCSO32.Oper.ctlVal
RB25–RB32 Remote Bits RB25–RB32
