F.24
SEL-787 Relay Instruction Manual Date Code 20150130
IEC 61850 Communications
Logical Nodes
METMSTA1 MaxA.instCVal.mag.f INMX Current, neutral, maximum magnitude
METMSTA1 MaxA1.phsA.instCVal.mag.f IAW1MX Winding1 current, A-phase, maximum magnitude
METMSTA1 MaxA1.phsB.instCVal.mag.f IBW1MX Winding1 current, B-phase, maximum magnitude
METMSTA1 MaxA1.phsC.instCVal.mag.f ICW1MX Winding1 current, C-phase, maximum magnitude
METMSTA1 MaxA1.res.instCVal.mag.f IGW1MX Winding1 current, residual, maximum magnitude
METMSTA1 MaxA2.phsA.instCVal.mag.f IAW2MX Winding2 current, A-phase, maximum magnitude
METMSTA1 MaxA2.phsB.instCVal.mag.f IBW2MX Winding2 current, B-phase, maximum magnitude
METMSTA1 MaxA2.phsC.instCVal.mag.f ICW2MX Winding2 current, C-phase, maximum magnitude
METMSTA1 MaxA2.res.instCVal.mag.f IGW2MX Winding2 current, residual, maximum magnitude
METMSTA1 MaxP2PV.phsAB.instCVal.mag.f VABMX Voltage, A-to-B-phase, maximum magnitude
METMSTA1 MaxP2PV.phsBC.instCVal.mag.f VBCMX Voltage, B-to-C-phase, maximum magnitude
METMSTA1 MaxP2PV.phsCA.instCVal.mag.f VCAMX Voltage, C-to-A-phase, maximum magnitude
METMSTA1 MaxPhV.phsA.instCVal.mag.f VAMX Voltage, A-phase-to-neutral, maximum magnitude
METMSTA1 MaxPhV.phsB.instCVal.mag.f VBMX Voltage, B-phase-to-neutral, maximum magnitude
METMSTA1 MaxPhV.phsC.instCVal.mag.f VCMX Voltage, C-phase-to-neutral, maximum magnitude
METMSTA1 MaxVA.instMag.f KVA3PMX Apparent power magnitude, 3-phase, maximum
METMSTA1 MaxVAr.instMag.f KVAR3PMX Reactive power magnitude, 3-phase, maximum
METMSTA1 MaxW.instMag.f KW3PMX Real power magnitude, 3-phase, maximum
METMSTA1 MinA.instCVal.mag.f INMN Current, neutral, minimum magnitude
METMSTA1 MinA1.phsA.instCVal.mag.f IAW1MN Winding1 current, A-phase, minimum magnitude
METMSTA1 MinA1.phsB.instCVal.mag.f IBW1MN Winding1 current, B-phase, minimum magnitude
METMSTA1 MinA1.phsC.instCVal.mag.f ICW1MN Winding1 current, C-phase, minimum magnitude
METMSTA1 MinA1.res.instCVal.mag.f IGW1MN Winding1 current, residual, minimum magnitude
METMSTA1 MinA2.phsA.instCVal.mag.f IAW2MN Winding2 current, A-phase, minimum magnitude
METMSTA1 MinA2.phsB.instCVal.mag.f IBW2MN Winding2 current, B-phase, minimum magnitude
METMSTA1 MinA2.phsC.instCVal.mag.f ICW2MN Winding2 current, C-phase, minimum magnitude
METMSTA1 MinA2.res.instCVal.mag.f IGW2MN Winding2 current, residual, minimum magnitude
METMSTA1 MinP2PV.phsAB.instCVal.mag.f VABMN Voltage, A-to-B-phase, minimum magnitude
METMSTA1 MinP2PV.phsBC.instCVal.mag.f VBCMN Voltage, B-to-C-phase, minimum magnitude
METMSTA1 MinP2PV.phsCA.instCVal.mag.f VCAMN Voltage, C-to-A-phase, minimum magnitude
METMSTA1 MinPhV.phsA.instCVal.mag.f VAMN Voltage, A-phase-to-neutral, minimum magnitude
METMSTA1 MinPhV.phsB.instCVal.mag.f VBMN Voltage, B-phase-to-neutral, minimum magnitude
METMSTA1 MinPhV.phsC.instCVal.mag.f VCMN Voltage, C-phase-to-neutral, minimum magnitude
METMSTA1 MinVA.instMag.f KVA3PMN Apparent power magnitude, 3-phase, minimum
METMSTA1 MinVAr.instMag.f KVAR3PMN Reactive power magnitude, 3-phase, minimum
METMSTA1 MinW.instMag.f KW3PMN Real power magnitude, 3-phase, minimum
RMS1MMXU2 A1.phsA.instCVal.mag.f IAW1RMS Winding1 RMS current, A-phase, magnitude
RMS1MMXU2 A1.phsB.instCVal.mag.f IBW1RMS Winding1 RMS current, B-phase, magnitude
Table F.13 Logical Device: MET (Metering) (Sheet 4 of 5)
Logical Node Attribute Data Source Comment
