F.23
Date Code 20150130 Instruction Manual SEL-787 Relay
IEC 61850 Communications
Logical Nodes
METMMXU1 PhV.phsA.instCVal.mag.f VA_MAG Voltage, A-phase-to-neutral, magnitude
METMMXU1 PhV.phsB.instCVal.ang.f VB_ANG Voltage, B-phase-to-neutral, angle
METMMXU1 PhV.phsB.instCVal.mag.f VB_MAG Voltage, B-phase-to-neutral, magnitude
METMMXU1 PhV.phsC.instCVal.ang.f VC_ANG Voltage, C-phase-to-neutral, angle
METMMXU1 PhV.phsC.instCVal.mag.f VC_MAG Voltage, C-phase-to-neutral, magnitude
METMMXU1 PhV.res.instCVal.ang.f VG_ANG Zero-sequence voltage, angle
METMMXU1 PhV.res.instCVal.mag.f VG_MAG Zero-sequence voltage, magnitude
METMMXU1 PPV.phsAB.instCVal.ang.f VAB_ANG Voltage, A-to-B-phase, angle
METMMXU1 PPV.phsAB.instCVal.mag.f VAB_MAG Voltage, A-to-B-phase, magnitude
METMMXU1 PPV.phsBC.instCVal.ang.f VBC_ANG Voltage, B-to-C-phase, angle
METMMXU1 PPV.phsBC.instCVal.mag.f VBC_MAG Voltage, B-to-C-phase, magnitude
METMMXU1 PPV.phsCA.instCVal.ang.f VCA_ANG Voltage, C-to-A-phase, angle
METMMXU1 PPV.phsCA.instCVal.mag.f VCA_MAG Voltage, C-to-A-phase, magnitude
METMMXU1 TotPF.instMag.f PF Power factor, 3-phase, magnitude
METMMXU1 TotVA.instMag.f S Apparent power, 3-phase, magnitude
METMMXU1 TotVAr.instMag.f Q Reactive power, 3-phase, magnitude
METMMXU1 TotW.instMag.f P Real power, 3-phase, magnitude
METMSQI1 SeqA1.c2.instCVal.ang.f 3I2W1ANG Winding1 current, negative-sequence, angle
METMSQI1 SeqA1.c2.instCVal.mag.f 3I2W1MAG Winding1 current, negative-sequence, magnitude
METMSQI1 SeqA1.c1.instCVal.ang.f I1W1_ANG Winding1 current, positive-sequence, angle
METMSQI1 SeqA1.c1.instCVal.mag.f I1W1_MAG Winding1 current, positive-sequence, magnitude
METMSQI1 SeqA1.c3.instCVal.ang.f IGW1_ANG Winding1 current, zero-sequence, angle
METMSQI1 SeqA1.c3.instCVal.mag.f IGW1_MAG Winding1 current, zero-sequence, magnitude
METMSQI1 SeqA2.c2.instCVal.ang.f 3I2W2ANG Winding2 current, negative-sequence, angle
METMSQI1 SeqA2.c2.instCVal.mag.f 3I2W2MAG Winding2 current, negative-sequence, magnitude
METMSQI1 SeqA2.c1.instCVal.ang.f I1W2_ANG Winding2 current, positive-sequence, angle
METMSQI1 SeqA2.c1.instCVal.mag.f I1W2_MAG Winding2 current, positive-sequence, magnitude
METMSQI1 SeqA2.c3.instCVal.ang.f IGW2_ANG Winding2 current, zero-sequence, angle
METMSQI1 SeqA2.c3.instCVal.mag.f IGW2_MAG Winding2 current, zero-sequence, magnitude
METMSQI1 SeqV.c2.instCVal.ang.f 3V2_ANG Voltage, negative-sequence, angle
METMSQI1 SeqV.c2.instCVal.mag.f 3V2_MAG Voltage, negative-sequence, magnitude
METMSQI1 SeqV.c1.instCVal.ang.f V1_ANG Voltage, positive-sequence, angle
METMSQI1 SeqV.c1.instCVal.mag.f V1_MAG Voltage, positive-sequence, magnitude
METMSQI1 SeqV.c3.instCVal.ang.f VG_ANG Voltage, zero-sequence, angle
METMSQI1 SeqV.c3.instCVal.mag.f VG_MAG Voltage, zero-sequence, magnitude
METMSTA1 AvAmps01.instMag.f IAVW1MAG Winding1 average current, magnitude
METMSTA1 AvAmps02.instMag.f IAVW2MAG Winding2 average current, magnitude
METMSTA1 AvVolts.instMag.f VAVE_MAG Average voltage, magnitude
Table F.13 Logical Device: MET (Metering) (Sheet 3 of 5)
Logical Node Attribute Data Source Comment
