F.22
SEL-787 Relay Instruction Manual Date Code 20150130
IEC 61850 Communications
Logical Nodes
METMDST1 PkDmdA.phsB.instCVal.mag.f IBPD Phase-B current peak demand
METMDST1 PkDmdA.phsC.instCVal.mag.f ICPD Phase-C current peak demand
METMDST1 PkDmdA.res.instCVal.mag.f IGPD Residual current peak demand
METMDST1 SupVArh.instMag.f MVARHN Reactive energy, 3-phase negative
METMDST1 SupWh.instMag.f MWHN Real energy, 3-phase negative
METMHAI1 ThdA1.phsA.instCVal.mag.f IAW1_THD Winding1 A-phase current THD
METMHAI1 ThdA1.phsB.instCVal.mag.f IBW1_THD Winding1 B-phase current THD
METMHAI1 ThdA1.phsC.instCVal.mag.f ICW1_THD Winding1 C-phase current THD
METMHAI1 ThdA1.neut.instCVal.mag.f IN_THD Neutral current THD
METMHAI1 ThdA2.phsA.instCVal.mag.f IAW2_THD Winding2 A-phase current THD
METMHAI1 ThdA2.phsB.instCVal.mag.f IBW2_THD Winding2 B-phase current THD
METMHAI1 ThdA2.phsC.instCVal.mag.f ICW2_THD Winding2 C-phase current THD
METMHAI1 ThdPhV.phsA.instCVal.mag.f VA_THD A-phase-to-neutral voltage THD
METMHAI1 ThdPhV.phsB.instCVal.mag.f VB_THD B-phase-to-neutral voltage THD
METMHAI1 ThdPhV.phsC.instCVal.mag.f VC_THD C-phase-to-neutral voltage THD
METMHAI1 ThdPPV.phsAB.instCVal.mag.f VAB_THD A-to-B-phase voltage THD
METMHAI1 ThdPPV.phsBC.instCVal.mag.f VBC_THD B-to-C-phase voltage THD
METMHAI1 ThdPPV.phsCA.instCVal.mag.f VCA_THD C-to-A-phase voltage THD
METMMXU1 A.neut.instCVal.ang.f IN_ANG Current, neutral, angle
METMMXU1 A.neut.instCVal.mag.f IN_MAG Current, neutral, magnitude
METMMXU1 A1.phsA.instCVal.ang.f IAW1_ANG Winding1 current, A-phase, angle
METMMXU1 A1.phsA.instCVal.mag.f IAW1_MAG Winding1 current, A-phase, magnitude
METMMXU1 A1.phsB.instCVal.ang.f IBW1_ANG Winding1 current, B-phase, angle
METMMXU1 A1.phsB.instCVal.mag.f IBW1_MAG Winding1 current, B-phase, magnitude
METMMXU1 A1.phsC.instCVal.ang.f ICW1_ANG Winding1 current, C-phase, angle
METMMXU1 A1.phsC.instCVal.mag.f ICW1_MAG Winding1 current, C-phase, magnitude
METMMXU1 A1.res.instCVal.ang.f IGW1_ANG Winding1 current, calculated-residual, angle
METMMXU1 A1.res.instCVal.mag.f IGW1_MAG Winding1 current, calculated-residual, magnitude
METMMXU1 A2.phsA.instCVal.ang.f IAW2_ANG Winding2 current, A-phase, angle
METMMXU1 A2.phsA.instCVal.mag.f IAW2_MAG Winding2 current, A-phase, magnitude
METMMXU1 A2.phsB.instCVal.ang.f IBW2_ANG Winding2 current, B-phase, angle
METMMXU1 A2.phsB.instCVal.mag.f IBW2_MAG Winding2 current, B-phase, magnitude
METMMXU1 A2.phsC.instCVal.ang.f ICW2_ANG Winding2 current, C-phase, angle
METMMXU1 A2.phsC.instCVal.mag.f ICW2_MAG Winding2 current, C-phase, magnitude
METMMXU1 A2.res.instCVal.ang.f IGW2_ANG Winding2 current, calculated-residual, angle
METMMXU1 A2.res.instCVal.mag.f IGW2_MAG Winding2 current, calculated-residual, magnitude
METMMXU1 Hz.instMag.f FREQ Frequency
METMMXU1 PhV.phsA.instCVal.ang.f VA_ANG Voltage, A-phase-to-neutral, angle
Table F.13 Logical Device: MET (Metering) (Sheet 2 of 5)
Logical Node Attribute Data Source Comment
