4.110
SEL-787 Relay Instruction Manual Date Code 20150130
Protection and Logic Functions
DNP Map Settings (SET DNP n Command, n = 1, 2, or 3)
Event Report Settings
Event reports can be either 15 cycles or 64 cycles in length as determined by
the LER setting. For LER of 15, the prefault length, PRE, must be in the range
1–10. The relay can hold at least seventy-seven 15-cycle event reports or
nineteen 64-cycle event reports.
Load Profile Settings
Use the LDLIST setting to declare the analog quantities you want included in
the Load Profile Report. Enter as many as 17 analog quantities, separated by
spaces or commas, into LDLIST setting. See Appendix K: Analog Quantities
for a list of the available Analog Quantities. Also set the LDAR to the desired
acquisition rate for the report.
IMPORTANT: All stored load data
are lost when changing the LDLIST.
DNP Map Settings (SET DNP n Command, n = 1, 2, or 3)
Table 4.68 shows the available settings. See Appendix D: DNP3
Communications for additional details.
Table 4.66 Event Report Settings
Setting Prompt Setting Range Setting Name := Factory Default
EVENT TRIGGER SELOGIC ER := 0
EVENT LENGTH 15, 64 cyc LER := 15
PREFAULT LENGTH 1–59 cyc PRE := 5
NOTE: Event report data stored in
the relay will be lost when you change
the LER setting, You must save the
data before changing the setting.
Table 4.67 Load Profile Settings
Setting Prompt Setting Range
Setting Name :=
Fac tory Default
LDP LIST NA, as many as 17 analog
quantities
LDLIST := NA
LDP ACQ RATE 5, 10, 15, 30, 60 min LDAR := 15
Table 4.68 DNP Map Settings
a
(Sheet 1 of 2)
Setting Prompt Setting Range
Setting Name :=
Fac tory Defau lt
DNP Binary Input Label Name 10 characters BI_00 := ENABLED
DNP Binary Input Label Name 10 characters BI_01 := TRIPXFMR
DNP Binary Input Label Name 10 characters BI_02 := TRIP1
DNP Binary Input Label Name 10 characters BI_03 := TRIP2
•
•
•
•
•
•
•
•
•
DNP Binary Input Label Name 10 characters BI_99 := NA
DNP Binary Output Label Name 10 characters BO_00 := RB01
•
•
•
•
•
•
•
•
•
DNP Binary Output Label Name 10 characters BO_31 := RB32
DNP Analog Input Label Name 24 characters AI_00 := IAW1_MAG
