Date _______________
Group______________
SET.7
of 66
SEL-787 Settings Sheets
Group Settings (SET Command)
Date Code 20150130 Instruction Manual SEL-787 Relay
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51P2AP := OFF)
51P2ACT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51P2AP := OFF)
51P2AMR :=
PH A TOC TRQCTRL (SEL
OGIC) (Hidden if 51P2AP := OFF) 51P2ATC :=
Winding 2 Phase B Time Overcurrent
PHASE TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.],
0.10–3.20 A [1 A nom.])
51P2BP :=
PHASE TOC CURVE (U1, U2, U3, U4, U5,
C1, C2, C3, C4, C5)
(Hidden if 51P2BP := OFF)
51P2BC :=
PHASE TOC TDIAL (0.50–15.00 for U1–U5 OR
0.05–1.00 for C1–C5)
(Hidden if 51P2BP := OFF)
51P2BTD :=
EM RESET DELAY (Y, N)
(Hidden if 51P2BP := OFF) 51P2BRS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51P2BP := OFF)
51P2BCT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51P2BP := OFF)
51P2BMR :=
PH B TOC TRQCTRL (SEL
OGIC) (Hidden if 51P2BP := OFF) 51P2BTC :=
Winding 2 Phase C Time Overcurrent
PHASE TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.],
0.10–3.20 A [1 A nom.])
51P2CP :=
PHASE TOC CURVE (U1, U2, U3, U4, U5,
C1, C2, C3, C4, C5)
(Hidden if 51P2CP := OFF)
51P2CC :=
PHASE TOC TDIAL (0.50–15.00 for U1–U5 OR
0.05–1.00 for C1–C5)
(Hidden if 51P2CP := OFF)
51P2CTD :=
EM RESET DELAY (Y, N)
(Hidden if 51P2CP := OFF) 51P2CRS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51P2CP := OFF)
51P2CCT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51P2CP := OFF)
51P2CMR :=
PH C TOC TRQCTRL (SEL
OGIC) (Hidden if 51P2CP := OFF) 51P2CTC :=
Winding 2 Residual Time Overcurrent
All settings below are hidden when W2CT := DELTA.
RES TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.], 0.10–3.20
A [1 A nom.])
51G2P :=
RES TOC CURVE (U1, U2, U3, U4, U5, C1, C2, C3, C4, C5)
(Hidden if 51G2P := OFF)
51G2C :=
RES TOC TDIAL (0.50–15.00 for U1–U5 OR 0.05–1.00 for
C1–C5)
(Hidden if 51G2P := OFF)
51G2TD :=
EM RESET DELAY (Y, N)
(Hidden if 51G2P := OFF) 51G2RS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51G2P := OFF)
51G2CT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51G2P := OFF)
51G2MR :=
RES TOC TRQCTRL (SEL
OGIC) (Hidden if 51G2P := OFF) 51G2TC :=
