Date _______________
Group______________
SET.43
of 66
SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
Date Code 20150130 Instruction Manual SEL-787 Relay
Unsolicited Message Max Retry Attempts (2–10)
(Hidden if UNSOL1 := N)
URETRY1 :=
Unsolicited Message Offline Time-Out (1–5000 sec)
(Hidden if UNSOL1 := N)
UTIMEO1 :=
Minimum Seconds from DCD to TX (0.00–1.00)
MINDLY :=
Maximum Seconds from DCD to TX (0.00–1.00)
MAXDLY :=
Settle Time from RTS On to TX (OFF, 0.00–30.00 sec)
PREDLY :=
Settle Time from TX to RTS OFF (0.00–30.00 sec)
PSTDLY :=
Modem Protocol (for DNP3 session and EIA-232 port only)
Modem Connected to Port (Y, N) MODEM :=
Modem Startup String (30 characters)
MSTR :=
Phone Number for Dial-Out (30 characters)
PH_NUM1 :=
Phone Number for Dial-Out (30 characters)
PH_NUM2 :=
Retry Attempts for Phone 1 Dial-Out (1–20)
RETRY1 :=
Retry Attempts for Phone 2 Dial-Out (1–20)
RETRY2 :=
Time to Attempt Dial (5–300 sec)
MDTIME :=
Time Between Dial-Out Attempts (5–3600 sec)
MDRET :=
Modbus Protocol
MODBUS SLAVE ID (1–247) (Hidden if PROTO := SEL, DNP,
PMU, EVMSG, or MB_)
SLAVEID :=
MIRRORED BITS Protocol
(Hidden if PROTO := SEL, DNP, PMU, EVMSG, or MOD.)
MB Transmit Identifier (1–4) TXID :=
MB Receive Identifier (1–4)
RXID :=
MB RX Bad Pickup Time (0–10000 seconds)
RBADPU :=
MB Channel Bad Pickup (1–10000 ppm)
CBADPU :=
MB Receive Default State (8 characters)
RXDFLT :=
RMB1 Pickup Debounce Messages (1–8)
RMB1PU :=
RMB1 Dropout Debounce Messages (1–8)
RMB1DO :=
RMB2 Pickup Debounce Messages (1–8)
RMB2PU :=
RMB2 Dropout Debounce Messages (1–8)
RMB2DO :=
RMB3 Pickup Debounce Messages (1–8)
RMB3PU :=
RMB3 Dropout Debounce Messages (1–8)
RMB3DO :=
RMB4 Pickup Debounce Messages (1–8)
RMB4PU :=
RMB4 Dropout Debounce Messages (1–8)
RMB4DO :=
RMB5 Pickup Debounce Messages (1–8)
RMB5PU :=
RMB5 Dropout Debounce Messages (1–8)
RMB5DO :=
RMB6 Pickup Debounce Messages (1–8)
RMB6PU :=
