SET.52
of 66
SEL-787 Settings Sheets
Report Settings (SET R Command)
Date _______________
Group______________
SEL-787 Relay Instruction Manual Date Code 20150130
CLEAR LB_ LABEL (7 characters) CLB30 :=
SET LB_ LABEL (7 characters)
SLB30 :=
PULSE LB_ LABEL (7 characters)
PLB30 :=
LB_NAME (14 characters)
NLB31 :=
CLEAR LB_ LABEL (7 characters)
CLB31 :=
SET LB_ LABEL (7 characters)
SLB31 :=
PULSE LB_ LABEL (7 characters)
PLB31 :=
LB_NAME (14 characters)
NLB32 :=
CLEAR LB_ LABEL (7 characters)
CLB32 :=
SET LB_ LABEL (7 characters)
SLB32 :=
PULSE LB_ LABEL (7 characters)
PLB32 :=
Report Settings (SET R Command)
SER Chatter Criteria
Auto-Removal Enable (Y, N) ESERDEL :=
Number of Counts (2–20 counts)
SRDLCNT :=
Removal Time (0.1–90.0 seconds)
SRDLTIM :=
SER Trigger Lists
SERn = As many as 24 Relay-Word elements separated by spaces or commas. Use NA to disable
setting.
SER1 :=
SER2 :=
SER3 :=
SER4 :=
Relay Word Bit Aliases
ALIASn= 'RW Bit'(space)'Alias'(space)'Asserted Text'(space)'Deasserted Text'. Alias, Asserted, and
Deasserted text strings can be as long as 15 characters. Use NA to disable setting.
Enable ALIAS (N, 1–20)
EALIAS :=
ALIAS 1
ALIAS1 :=
ALIAS 2
ALIAS2 :=
ALIAS 3
ALIAS3 :=
ALIAS 4
ALIAS4 :=
ALIAS 5
ALIAS5 :=
ALIAS 6
ALIAS6 :=
ALIAS 7
ALIAS7 :=
ALIAS 8
ALIAS8 :=
ALIAS 9
ALIAS9 :=
