A.4
SEL-787 Relay Instruction Manual Date Code 20150130
Firmware and Manual Versions
Firmware
➤ Added calculated phase-to-phase voltages for wye-connected PTs to
the analog quantities to allow selection for display points.
➤ Implemented improved diagnostics and actions in the relay self-tests.
For certain failures, the relay will automatically restart as many as three
times.
➤ Corrected issue with Inverse Time Overcurrent elements (did not
accumulate time correctly at off-nominal frequency).
SEL-787-R203-V0-Z002001-D20100730
➤ Added new Winding 1 and Winding 2, level 1, Phase A, Phase B and
Phase C instantaneous overcurrent elements.
➤ Added new Winding 1 and Winding 2 Phase A, Phase B and Phase C
time-overcurrent elements.
➤ Updated the error messages for setting interdependency checks to
match the global setting AOx0yH.
➤ Extended the CT ratio setting range to 1:10000 for 5 A CTs and
1:50000 for 1 A CTs.
➤ Enhanced REF element logic by adding 52A interlock (new setting
REF52BYP).
➤ Added capability to support two Modbus TCP sessions with timeout
settings on the Ethernet port.
➤ Added Select Before Operate control (SBO) to the IEC 61850 protocol.
➤ Added Access Control setting BLOCK MODBUS SET
(BLKMBSET) to be able to block settings changes from a remote
Modbus or DeviceNet master.
➤ Added new I/O card option of 4 DI/3 DO, which has one Form-B and
two Form-C outputs.
➤ Corrected relay status reporting via Modbus when relay is disabled.
➤ Updated Ethernet port settings IPADDR, SUBNETM, and DEFRTR
validation to allow addresses in the private address space.
➤ Added FASTOP setting to Port 1 (Ethernet) settings to allow breaker
control using Fast Operate.
➤ Added IRIG-B input capability to fiber-optic serial Port 2 option
including a new Time-Synchronization Source setting TIME_SRC.
➤ Added front-panel setting FP_AUTO to allow choice between
OVERRIDE and ROTATING display messages.
20100730
SEL-787-R202-V0-Z001001-D20100215
➤ Factory calibration improvements. Only R200–R201 can be upgraded
to R202 firmware.
20100215
SEL-787-R201-V0-Z001001-D20100118
➤ Corrected an occasional IEC 61850 communications defect where the
firmware incorrectly reads an opcode from Flash memory and results
in a vector.
20100118
SEL-787-R200-V0-Z001001-D20091015
➤ Revised firmware for processor update. Previous versions cannot be
upgraded to R200.
➤ Extended event report storage capability to at least seventy-seven
15-cycle or nineteen 64-cycle event reports.
20091015
Table A.1 200 Series Firmware Revision History (Sheet 4 of 4)
Firmware Identification (FID) Number
Summary of Revisions
Manual
Date Code
