Modbus RTU Communications
Communications Protocol
Instruction Manual
Table E.33 Modbus Register Labels for Use With SET M Command (Sheet 1 of 3)
Register
Address
Label
644 FPGA
645 GPSB
646 HMI
647 RAM
648 ROM
649 CR_RAM
650 NON_VOL
651 CLKSTS
652 CID_FILE
653 RTD
654 P3P3PS
655 P5PS
656 P2P5PS
657 P3P75PS
658 N1P25PS
659 N5PS
660 CLKBAT
661 CTBRD
662 CARDC
663 CARDD
664 CARDE
665 IAW1STS
666 IBW1STS
667 ICW1STS
668 IAW2STS
669 IBW2STS
670 ICW2STS
671 INSTS
672 VASTS
673 VBSTS
674 VCSTS
675 RLYSTS
676–683
a
684 IAW1_MAG
685 IAW1_ANG
686 IBW1_MAG
687 IBW1_ANG
688 ICW1_MAG
689 ICW1_ANG
690 IGW1_MAG
691 IGW1_ANG
692 3I2W1MAG
693 IAVW1MAG
694 IAW2_MAG
695 IAW2_ANG
696 IBW2_MAG
697 IBW2_ANG
698 ICW2_MAG
699 ICW2_ANG
700 IGW2_MAG
701 IGW2_ANG
702 3I2W2MAG
703 IAVW2MAG
704 IN_MAG
705 IN_ANG
706–708
a
709 VAB_MAG
710 VAB _ AN G
711 VBC_MAG
712 VBC_ANG
713 VCA_MAG
714 VCA_ANG
715 VAVE_MAG
716 VA_ M A G
717 VA_ANG
718 VB_MAG
719 VB_ANG
720 VC_MAG
721 VC_ANG
722 VG_MAG
723 VG_ANG
724 VAVE _ MAG
725 3V2_MAG
726 P
727 Q
728 S
729 PF
730 VHZ
731 FREQ
732 MWHPH
733 MWHPL
734 MWHNH
735 MWHNL
736 MVRHPH
737 MVRHPL
738 MVRHNH
739 MVRHNL
740 ENRGY_S
741 ENRGYMN
742 ENRGY_H
743 ENRGY_D
744 ENRGYMO
Register
Address
Label
745 ENRGY_Y
746–753
a
754 IAD
755 IBD
756 ICD
757 IGD
758 3I2D
759 IAPD
760 IBPD
761 ICPD
762 IGPD
763 3I2PD
764 PDEM_R_S
765 PDEM_RMN
766 PDEM_R_H
767 PDEM_R_D
768 PDEM_RMO
769 PDEM_R_Y
770 IAW1_THD
771 IBW1_THD
772 ICW1_THD
773 IAW2_THD
774 IBW2_THD
775 ICW2_THD
776 VA_THD
777 VB_THD
778 VC_THD
779 VAB _ TH D
780 VBC_THD
781 VCA_THD
782 RTDAMB
783 RTDOTHMX
784 RTD1
785 RTD2
786 RTD3
787 RTD4
788 RTD5
789 RTD6
790 RTD7
791 RTD8
792 RTD9
793 RTD10
794 RTD11
795 RTD12
796–806
a
807 IAW1RMS
Register
Address
Label
808 IBW1RMS
809 ICW1RMS
810 IAW2RMS
811 IBW2RMS
812 ICW2RMS
813 INRMS
814 VARMS
815 VBRMS
816 VCRMS
817 VA B R MS
818 VBCRMS
819 VCARMS
820 IAW1MX
821 IAW1MN
822 IBW1MX
823 IBW1MN
824 ICW1MX
825 ICW1MN
826 IGW1MX
827 IGW1MN
828 IAW2MX
829 IAW2MN
830 IBW2MX
831 IBW2MN
832 ICW2MX
833 ICW2MN
834 IGW2MX
835 IGW2MN
836 INMX
837 INMN
838 VABMX
839 VA B M N
840 VBCMX
841 VBCMN
842 VCAMX
843 VCAMN
844 KW3PMX
845 KW3PMN
846 KVAR3PMX
847 KVAR3PMN
848 KVA3PMX
849 KVA3PMN
850 FREQMX
851 FREQMN
852 RTD1MX
853 RTD1MN
Register
Address
Label
