E.28
SEL-787 Relay Instruction Manual Date Code 20150130
Modbus RTU Communications
Modbus Register Map
370 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 470
371 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 471
372 (R/W) WDG2 IOC L2 EN 0 1 0 472
0=N
1=Y
373 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 473
374 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 474
375 (R/W) WDG2 IOC L3 EN 0 1 0 475
0=N
1=Y
376 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 476
377 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 477
378 (R/W) WDG2 IOC L4 EN 0 1 0 478
0=N
1=Y
379 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 479
380 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 480
Winding 2 Residual Instantaneous Overcurrent (WDG2 Res IOC)
381 (R/W) WDG2 RESIOC L1EN 0 1 0 481
0=N
1=Y
382 (R/W) RES IOC LEVEL A 10 9600 200 0.01 482
383 (R/W) RES IOC DELAY sec 0 500 50 0.01 483
384 (R/W) WDG2 RESIOC L2EN 0 1 0 484
0=N
1=Y
385 (R/W) RES IOC LEVEL A 10 9600 200 0.01 485
386 (R/W) RES IOC DELAY sec 0 500 50 0.01 486
Winding 2 Negative-Sequence Instantaneous Overcurrent (WDG2 Neg Seq IOC)
387 (R/W) W2 NSEQ IOC L1EN 0 1 0 487
0=N
1=Y
388 (R/W) NSEQ IOC LEVEL A 10 9600 200 0.01 488
389 (R/W) NSEQ IOC DELAY sec 1 1200 2 0.1 489
390 (R/W) W2 NSEQ IOC L2EN 0 1 0 490
0=N
1=Y
391 (R/W) NSEQ IOC LEVEL A 10 9600 200 0.01 491
392 (R/W) NSEQ IOC DELAY sec 1 1200 2 0.1 492
Winding 2 Maximum Phase Time-Overcurrent (WDG2 Max Ph TOC)
393 (R/W) WDG2 TOC ENABLE 0 1 0 493
0=N
1=Y
394 (R/W) PHASE TOC LEVEL A 10 1600 120 0.01 494
395 (R/W) PHASE TOC CURVE 0 9 2 495
0 = U1 5 = C1
1 = U2 6 = C2
2 = U3 7 = C3
3 = U4 8 = C4
4 = U5 9 = C5
396 (R/W) PHASE TOC TDIAL 5 1500 300 0.01 496
397 (R/W) EM RESET DELAY 0 1 0 497
Table E.34 Modbus Register Map
a
(Sheet 6 of 36)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fac tor
DeviceNet
Parameter
Numbers
