F.30

SEL-787 Relay Instruction Manual Date Code 20150130

IEC 61850 Communications

Protocol Implementation Conformance Statement

defineNamedVariableList

getNamedVariableListAttributes Y

deleteNamedVariableList

defineNamedType

getNamedTypeAttributes

deleteNamedType

input

output

takeControl

relinquishControl

defineSemaphore

deleteSemaphore

reportPoolSemaphoreStatus

reportSemaphoreStatus

initiateDownloadSequence

downloadSegment

terminateDownloadSequence

initiateUploadSequence

uploadSegment

terminateUploadSequence

requestDomainDownload

requestDomainUpload

loadDomainContent

storeDomainContent

deleteDomain

getDomainAttributes Y

createProgramInvocation

deleteProgramInvocation

start

stop

resume

reset

kill

getProgramInvocationAttributes

obtainFile

defineEventCondition

deleteEventCondition

getEventConditionAttributes

Table F.19 MMS Service Supported Conformance (Sheet 2 of 3)
