Page 246 OmniTrax Product Guide
Processor
Controls
• all control adjustments are made via the Universal Configuration
Module (software application)
• automated sensitivity profile for each cable set
• automated transmission power level for each cable set
• up to 50 defined cable segments per cable set (100 per processor)
• up to 50 software defined sensor zones per processor
• calibrated alarm threshold for each defined cable segment
• calibrated alarm threshold for each meter of sensor cable
• adjustable target speed settings
• remote self-test inputs (local control mode)
Connectors
• board-mounted TNC connectors for internal mini-coaxial cables
• external bulkhead connectors for lead-in cables
• removable terminal block for power input
• removable terminal block for relay output connections
• removable terminal block for auxiliary device/self-test inputs
• USB port for UCM connection
• 40-pin socket for auxiliary cards (NIC, ROC)
• Compact Flash memory plug-in connector
• locking 2-pin header for battery connection
• locking 2-pin header for enclosure tamper connection
Outputs
• 4 form C relay outputs 30 VDC @ 1.0 A maximum, non-inductive
load
• one sensor alarm relay for each cable set (A-side and B-side)
• one supervision relay, and one fail relay per processor
LED indicators
• one each per output relay, eight diagnostic, four internal function,
one each for TX and RX
Supervision
• mechanical enclosure tamper switch
• sensor cables
• lead-in cable
• processor operation
• power fail
• auxiliary inputs
Lightning protection
• transorbs and gas discharge pellets on all I/O - relay outputs,
communication lines, auxiliary device/self-test inputs, power inputs
• additional protection available for sensor cables and data lines
Grounding requirements
• earth ground connection at each processor (5
max. recommended)
Temperature
• -40º to +70º C (-40º to +158º F) as measured inside enclosure
Relative humidity
• 0 to 95%, non-condensing
Auxiliary cards
• Network Interface Card (one NIC is required by each processor
using Silver Network communication)
• EIA-422 copper wire
• multi-mode fiber optic cable
• single-mode fiber optic cable
• EIA-422/multi-mode fiber
• EIA-422/single-mode fiber
• Relay Output Card (ROC) - provides 8 additional relay outputs (one
ROC per processor, cannot be used with UIC)
• Universal Input Card (UIC) - provides 8 additional inputs
(one ROC per processor, cannot be used with UIC)
• NOTE - auxiliary card power consumption is included in the
processor’s rating
