OmniTrax Product Guide Page 247
Sensor Cable
Description
• OC2 - 300 or 400 m with 20 m integral lead-in, includes connectors
and ferrite beads
• SC1 - 50 to 200 m lengths in 50 m increments, TX and RX cables
encased in a single outer jacket, 20 m integral lead-in, field installed
connectors and ferrite beads
• SC2 - 50 to 200 m lengths in 50 m increments, separate TX and RX
cables, 20 m integral lead-in, field installed connectors and ferrite
beads
Minimum length (lead-in)
• a minimum length of 6 m (20 ft.) of lead-in cable is required
Minimum length (sensor
cable including lead-in)
• for sensor cable that is connected to another sensor cable through
decouplers (two processors) the minimum length of sensor cable is
75 m (246 ft.) per processor (150 m between two processors)
• for sensor cable that is terminated (not connected to another sensor
cable through decouplers) the minimum length of sensor cable is
16 m (52 ft.)
Operational temperature
• -40º to +70ºC (-40º to +158ºF)
Storage temperature
• -50º to +85ºC (-58º to +185ºF)
48 VDC Network
power supply
Part number
• A4EM0200
Enclosure
• mounted in a painted aluminum CSA type 4 enclosure (equivalent to
NEMA 4 IP66) 26 x 23 x 13 cm (11 x 9 x 5 in.)
Quantity
• maximum 5 processors from one 48 VDC supply, with the middle
processor connected to the supply, and power distributed to the other
processors over the sensor cables
Power input
• 115/230 VAC, 47 - 63 Hz
Power output
• 48 VDC, 3A maximum, 100 W
12 VDC
power supply
Part number
• C7EM0503
Enclosure
• no enclosure
Quantity
• one per processor
Power input
• 115/230 VAC, 60/50 Hz
Power output
• 12 VDC, 80 W
Auxiliary power
supply module
Part number
• 00EM0400
Power input
•48 VDC
Power consumption
•2 W
Power output
• 12 VDC @ 150 mA maximum
