Silver Network
Network control
• Network Manager (Windows-based software) - 1 required per Silver
Network, max. 10 NMs on one PC, communicates with and controls
Silver Network based sensors, reports status to Windows-based
security management systems via TCP/IP communications
Number of devices
• up to 60 sensors per Silver Network
Network transmission media/
Device separation distance
• EIA-422 - 1.2 km (1300 yd.)
• multi-mode fiber - 2.2 km (2400 yd.)
• single-mode fiber - 10 km (10900 yd.)
• OC2 sensor cable - 800 m (875 yd.)
• SC1/SC2 sensor cable - 400 m (437 yd.)
NIU to NM communication
•USB
•EIA-232
• Ethernet
Network communication
• point-to-point
• 57.6 k bps (fixed)
• two channels (A-side, B-side)
Response time
• 1.0 second or less from alarm source to Network Manager
(for each network loop, not using Ethernet communications)
Network Interface Unit
• two variants - multi-mode fiber, single-mode fiber
• NIU - 1 required per Silver Network, 2 required for full redundancy,
dual channel (A-side, B-side),
• two communication ports to NW devices - EIA-422, fiber optic
• three communication ports to NM - EIA-232, USB, Ethernet
• USB port for UCM connection
• 12 to 48 VDC power input
• power LED, communication LEDs for all modes
• does not count against the total number of network devices
Network data terminations
• on sensor cable at end of perimeter
Network repeaters
• three variants - EIA-422, multi-mode fiber, EIA-422 and multi-mode
fiber
• double the maximum separation distance between devices
• 12 to 48 VDC power input, 2 W max. consumption
