System drawings
Page 78 OmniTrax Product Guide
Figure 45: Sample site drawing (network system - processor configuration)
B
PROCESSOR #1 CONFIGURATION
EQUIPMENT
PART NUMBER
PROCESSOR & ENCLOSURE
A4EM0101
TELECOM STYLE ENCLOSURE
RELAY OUTPUT CARD
NETWORK INTERFACE CARD
OC2 CABLE SET 300M
OC2 CABLE SET 400M
OC2 TERMINATOR
A4MA0200
00BA0400
00BA0302
A4FG0121
A4FG0120
A4KT01300
SENSOR CABLE
LIGHTNING ARRESTORS
A4KT1000
DATA LINE
LIGHTNING ARRESTORS
E0302
PROCESSOR SETTINGS
SYNCHRONIZATION
SYNC MASTER
SUPERVISION
A-SIDE = CABLE PAIR
B-SIDE = CLUTTER
NETWORK COMMUNICATION
CoaxA > 422/FOB
CABLE TYPE
OC2
NETWORK ADDRESS
1
AUX CONTROL
REMOTE
AUX CARD
RELAY
RELAY ACTIVATION
LATCHING
FUSES
F3 IN, F4 OUT
PROCESSOR & ENCLOSURE
A4EM0101
PROCESSOR #4 CONFIGURATION
EQUIPMENT
PART NUMBER
TELECOM STYLE ENCLOSURE
A4MA0200
RELAY OUTPUT CARD
00BA0400
NETWORK INTERFACE CARD
00BA0302
OC2 CABLE SET 300M
A4FG0121
OC2 CABLE SET 400M
A4FG0120
OC2 TERMINATOR
A4KT01300
SENSOR CABLE
LIGHTNING ARRESTORS
A4KT1000
DATA LINE
LIGHTNING ARRESTORS
E0302
PROCESSOR SETTINGS
SYNCHRONIZATION
ACCEPT SYNC
SUPERVISION
A-SIDE = CLUTTER
B-SIDE = CABLE PAIR
NETWORK COMMUNICATION
422/FOA > CoaxB
CABLE TYPE
OC2
NETWORK ADDRESS
4
AUX CONTROL
REMOTE
AUX CARD
RELAY
RELAY ACTIVATION
LATCHING
FUSES
F4 IN, F3 OUT
LTR
DESCRIPTION
CONFIGURATION BASELINE
DATE
APPD
PROCESSOR #2 CONFIGURATION
EQUIPMENT
PART NUMBER
PROCESSOR & ENCLOSURE
A4EM0101
TELECOM STYLE ENCLOSURE
A4MA0200
RELAY OUTPUT CARD
00BA0400
NETWORK INTERFACE CARD
00BA0302
OC2 CABLE SET 300M
A4FG0121
OC2 CABLE SET 400M
A4FG0120
SENSOR CABLE
LIGHTNING ARRESTORS
A4KT1000
PROCESSOR SETTINGS
SYNCHRONIZATION
ACCEPT SYNC
SUPERVISION
= CABLE PAIR
NETWORK COMMUNICATION
Coax
CABLE TYPE
OC2
NETWORK ADDRESS
2
AUX CONTROL
REMOTE
AUX CARD
RELAY
RELAY ACTIVATION
LATCHING
FUSES
F3 & F4 OUT
PROCESSOR #3 CONFIGURATION
EQUIPMENT
PART NUMBER
PROCESSOR & ENCLOSURE
A4EM0101
TELECOM STYLE ENCLOSURE
A4MA0200
RELAY OUTPUT CARD
00BA0400
NETWORK INTERFACE CARD
00BA0302
OC2 CABLE SET 300M
A4FG0121
OC2 CABLE SET 300M
A4FG0121
SENSOR CABLE
LIGHTNING ARRESTORS
A4KT1000
PROCESSOR SETTINGS
SYNCHRONIZATION
ACCEPT SYNC
SUPERVISION
= CABLE PAIR
NETWORK COMMUNICATION
Coax
CABLE TYPE
OC2
NETWORK ADDRESS
3
AUX CONTROL
REMOTE
AUX CARD
RELAY
RELAY ACTIVATION
LATCHING
FUSES
F3 & F4 OUT
SIZE
FSCM No.
PART NUMBER
DRAWING NUMBER
VAR.
54
SHEET
SCALE
Sample OmniTrax OC2 Site Plan
(4 Processors, 1 Microwave)
OF
