Z1 2inc
DXY 40%
DZ 2
UXY 0
UZ 0
Insertion Oscillation
EW Maximum insertion an‐
gle
Solid machining Complete machining
4. Press the "Accept" softkey.
7. Milling a circumferential slot
1. Press the "Milling", "Groove" and "Circ. groove" softkeys.
The "Circumferential Groove" input window opens.
2. Enter the following technology parameters:
T End_mill_8mm D1 F 0.018 mm/tooth FZ 0.010 mm/tooth
V 230 m/min
3. Enter the following parameters:
Machining Roughing (∇)
Circular pattern Pitch circle
X0 85abs
Y0 135abs
Z0 0abs
N 1
R 40
α0 180degrees
α1 180degrees
W 10
Z1 3inc
DZ 3
UXY 0mm
4. Press the "Accept" softkey.
Creating a ShopMill program
9.18 Example, standard machining
Milling
362 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
