Parameter Description
X0
Y0
Z0
The positions refer to the center point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
N Number of edges
R Radius of circumferential slot mm
α1 Opening angle of the slot Degrees
α2 Advance angle - (for pitch circle only) Degrees
W Slot width mm
Z1 Slot depth (abs) or depth in relation to Z0 (inc) - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
DZ Maximum depth infeed – (only for ∇ and ∇∇∇ edge) mm
FS Chamfer width for chamfering - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
UXY Plane finishing allowance - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
Positioning Positioning motion between the slots:
Straight line:
Next position is approached linearly in rapid traverse.
Circular:
Next position is approached along a circular path at the feedrate defined in the
machine data.
* Unit of feedrate as programmed before the cycle call
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
Parameter Description Value Can be set in SD
PL (only for G code) Machining plane Defined in MD
52005
SC (only for G
code)
Safety clearance 1 mm x
α0 Angle of rotation / starting angle
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Programming technological functions (cycles)
10.2 Milling
Milling
460 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
