Parameter Description Unit
Direction of rotation
Z Target position in the Z direction (abs and inc) mm
X Target position in the X direction (abs and inc) mm
K Center of the circle K (inc) - only if circle input via end point and center point
Note:
Incremental dimensions: The sign is also evaluated.
mm
I Center of circle I (inc) - only if circle input via end point and center point mm
PL Circle plane
● XY IJ
● YZ JK
● ZX KI
Working with Manual Machine
16.6 Simple workpiece machining
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 841
