Simplex 4010 User Manual

8-20
TBL
When using the input condition qualifier TBL (Trouble), a statement is true
when the point indicated in Field 4 is in trouble. Field 4 choices for the TBL
qualifier are:
• CPU Card Points
• System Card Points
• Power Supply Points
• Digital Pseudo Points
Note: The statement holds true until the point indicated in Field 4 not in
trouble.
[ ] [ ] [TBL] [3-01]
Figure 8-24
Example: The condition of 3-01 is TBL. The input of the equation remains
true until the point indicated in Field 4 is not in trouble.
TBL ACK
When using the input condition qualifier TBL ACK (Trouble Acknowledge), a
statement is true when the point indicated in Field 4 is in trouble and requires an
acknowledge. Field 4 choices for the TBL ACK qualifier are:
• CPU Card Points
• System Card Points
• Power Supply Points
• Digital Pseudo Points
Note: The statement holds true until the point indicated in Field 4 (in
trouble) is Acknowledged.
[ ] [ ] [TBL ACK] [3-01]
Figure 8-25
Example: The condition of 3-01 is TBL ACK. The input of the equation
remains true until the point indicated in Field 4 is acknowledged.
Continued on next page
Custom Control Programming, Continued
Fields 3 & 4 (Continued)
Field 1
Field 1
Field 2
Field 2
Field 3
Field 3
Field 4
Field 4
FIRST
STATEMENT
FIRST
STATEMENT
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
